GOOD DESIGN type spraying sterilizing and cooling machine
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
new type fruits and vegetables dehydration machines
Quality Choice
-
SJN3 tri-effect external circulating vacuum evaporator machine
-
SJN1 single-effect external circulating juice evaporator machine
-
SJN2 dual-effect external circulator evaporator machine
-
hot sales TN model extracting and concentrating line
-
NS model external circulating continuous concentrating boiler machine
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | KEWEI | Model Number | PLS-1000 | |
| Voltage | 380V | Power(W) | 9.6KW | |
| Dimension(L*W*H) | 9880*2250*1735mm | Certification | CE | |
| Warranty | one year | After-sales Service Provided | No overseas service provided | |
| Type | Other, Ultraviolet |
Product Description
Summary:
Continuous spraying sterilizer is designed and made on the basis of absorbing and digesting abroad machine.It adopts warm water to preheat,sterilize will recycling hot water,recycling warm water to pre-cool,and cooling water to cool,it is with the advantages of sterilizing temperature automatic control,and adjustable sterilizing time,and can be widely used in sterilizing and cooling of juice and beverage in various bottles and cans,electrolyte beverage,wine and condiments.It can be design and made to the sterilization conditions and production provided by the customer.
Technical parameters
Name | Model | PLS-1000 | PLS-2000 | PLS-3000 | PLS-5000 | |||
The hingest sterilizing temperature | 100 | |||||||
The width of sterilization transferring belt | 1500mm | |||||||
Transferring belt speed | 110-553mm/min(stepless speed) | |||||||
Heating steam pressure | 0.4MPa | |||||||
Length of sterilization step(mm) | 9000 | 16000 | 22000 | 320000 | ||||
Length of pre cooling step(mm) | 1200 | 1600 | 1800 | 2200 | ||||
Length of cooling step(mm) | 3000 | 5000 | 8000 | 10000 | ||||
Heating recycling water volume(m3) | 21 | 25 | 35 | 50 | ||||
Power (kw) | 9.6 | 10.6 | 13.6 | 16.5 | ||||
Size (mm) | Length | 9880 | 17880 | 23800 | 34880 | |||
Width | 2250 | |||||||
Height | 1735 | |||||||
