CNC Thread Milling Machine for Screw Rods SK6432

CNC Thread Milling Machine for Screw Rods SK6432 thumbnail-1
CNC Thread Milling Machine for Screw Rods SK6432 photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shaanxi, China
Brand Name:
HJMT
Contact Supplier Request Quote Chat Now
Shaanxi Hanjiang Machine Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Other China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shaanxi, China
Brand Name HJMT
Model Number SK6432
Type Vertical
CNC or Not CNC
Voltage 110~450 V
Power(W) 50~120 KW
Weight 15 Tons
Certification ISO9001:2008
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

CNC thread milling machine for Screw rods SK6432





Max. mounting diameter                  320mm

Max. center distance                    1200mm

Max. thread diameter to be milled       270mm

Max. thread length                      1000mm

Max. helix angle to be milled             ±60°

Number of starts                        1~99 (free)

Max. teeth depth                           60mm

Speed of head spindle                     0.5~10r/min

Max. longitudinal traverse of work table       1100mm

Max. cross traverse of tool carrier            280mm

Motor power of Milling cutter                  30KW

Cutter size:

O.D.                      φ254mm~φ150mm

I.D.                      φ60mm

width                     102mm

  speed of cutter spindle       150~300r/min

Max. weight of workpiece       200Kg
