Help CenterFoam Cutting Machine (HW-FM2212HL)
Related Products
cnc contour foam cutting machine
Application:
For cutting a wide range of materials including flexible and rigid polyurethanes, cellular glass, phenolic foam, PIR, fiber and expanded polystyrene (EPS), Typical examples of cut parts include complex packaging shapes and surfboards, utilized for block trimming (vertical wire), top trimming (horizontal wire), and cutting of 2D and 3D parts using both wires for shape cutting and slitting Features:Computer controlled, high precision, high-speed machine Special wire minimizes dust Operated from a single console, utilizing powerful and easy to use design, nesting and cutting software; all machine operations and diagnostic data can be viewed Perfect for stack cutting. Process a profile exactly as drawn, minimizing quality control issues Conveyor transport for easy block handling Easy integration into existing systems Electronic eye for automatic block positioning and auto start profiles Advanced nesting software for maximum block yield and minimal cut time of multiple shapes Control panel air conditioner Wireless.
Remote Control Specifications:
|
Model
|
HW-FM1310HL |
HW-FM2212HL |
|
Max. Block Height
|
1016mm |
1200mm |
|
Max. Block Width
|
1350mm |
2200mm |
|
Max. Cutting Speed
|
10 m/min(31 ft/min) |
10 m/min(31 ft/min) |
|
Floor Space Required
| ||
|
Width
|
3290mm |
4170mm |
|
Length
|
5300mm |
5300mm |
|
Height
|
2650mm |
2650mm |
|
Shipping weight
|
3550-4000kg (7850-8850lbs) |
|
