SJ-B110 Water-cooling Plastic Recycling Machine
Specifications:
Water-cooling Plastic Recycling Machine:This machine is suitable for regeneration and granulation of waste plastics,as HDPE,LDPE
Use:
This machine is suitable for regeneration and granulation of waste plastics,as HDPE,LDPE,and PP,etc.
It is equipped with quick motor-operated filter-screen-replacing unit and automatic temperature control.
The granulating crusher uses adjustable speed motor,pelleting with an extruding machine at the same
discharging speed synchronistically.The unit is easy to operate,with a high output,steady performance,
and favorable economic benefit
Main Technical Variables:
Model |
SJ-B90 |
SJ-B100 |
SJ-B110 |
SJ-B120 |
Type Diameter of Screw Stem |
φ90 |
φ100 |
φ110 |
φ120 |
Major Diameter Ratio of Screw Stem |
L/D 201 -221 |
L/D 201 -221 |
L/D 201 -221 |
L/D 201 -221 |
Rational Speed of Screw Stem |
10-100r/min |
10-100r/min |
10-100r/min |
10-100r/min |
Main Motor Power |
22kw |
30kw |
37kw |
45kw |
Output |
68kg/h |
95kg/h |
120kg/h |
135kg/h |
Weight of overall(kg) |
2t |
2.1t |
2.2t |
2.5t |
Cover dimensions (L×W×H) (mm) |
8000×1200×1800 |
8200×1600×1800 |
8500×1600×1800 |
8800×1600×1800 |
