Product Details

Condition:	New	Application:	Film	Plastic Processed:	Other, HDPE,LDPE,LLDPE
Blow Moulding Type:	Extrusion Blow Moulding	Automatic:	Yes	Place of Origin:	Zhejiang, China
Brand Name:	JINGDIANRUIHUA	Model Number:	LD/LLDPEE	Voltage:	220V
Power(W):	55kw	Dimension(LWH):	959.5M	Certification:	CE/ISO9000
Warranty:	one year	After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

polypropylene film blowing machine

Characteristics:

1.Suitable for produce agriculture film of 100% LLDPE or LLDPE

mix with other raw material

2.Adopt the most newly advanced technology as heat flow way,

extrude to shape film,special for mulch air ring

3.Has lots of advantage like design science,operate and maintain conveniently,stably performance.

4.Has the character of good plasticize, high physical and mechanical performance,strong tear resistance.

Main Technical Variables:

MODEL	SD/L-65B	SD/L-80B	SD/L-100B	SD/L-120B
SUITABLE MATERIAL	LDPE LLDPE
FILM WIDTH(mm)	800-1500mm	1000-2000mm	1500-2500mm	1800-3000mm
FILM THICKNESS (mm)	0.015-0.15mm	0.015-0.15mm	0.015-0.15mm	0.015-0.15mm
MAX.EXTRUSION OUTPUT	150kg/hr	280kg/hr	350kg/hr	450kg/hr
EXTRUDER
SCREW DIAMETER(mm)	φ65	φ80	φ100	φ120
SCREW L/D LENGTH	28:1
SCREW MATERIAL	SACM-645/38 CRMOALA
CYLINDER MATERIAL	SACM-645/38 CRMOALA
CYLINDER COOLING	550W×3	550W×3	750W×4	750W×4
DRIVING MOTOR(Kw)	37 Kw	55 Kw	90 Kw	110 Kw
TEMPERATURE CONTROL	4	4	5	5
AVERAGE POWER-CONSUME(Kw)	45 Kw	65 Kw	90 Kw	110 Kw
TYPE OF DIE
DIE SIZE(mm)	φ350/400	φ400/500	φ500/600	φ700/800
TEMPERATURE CONTROL	3	4	4	5
AIR RING	1
AIR BLOWER(Kw)	5.5 Kw	5.5 Kw	11 Kw	15 Kw
TAKE-UPUNIT
PINCH ROLLER (DIA. WIDTH)mm	φ165×1600	φ190×2100	φ220×2600	φ220×3200
TAKE-UP SPEED(m/min)	5-60 m/min	5-60 m/min	5-60 m/min	5-40 m/min
TAKE-UP MOTOR(Kw)	1.5 Kw	2.2 Kw	2.2 Kw	2.2 Kw
WINDING UNIT
TYPE	SURFACE FRICTION TYPE
WINDING MOTOR(Kw)	1.5 Kw	1.5 Kw	2.2 Kw	2.2 Kw
WINDING SPEED(m/min)	5-60 m/min	5-60 m/min	5-60 m/min	5-40 m/min
COVER DIMENSION(L×W×H)	6.8×2.6×7.0m	7.5×3.2×7.5m	9.0×4.2×10m	11×5.0×11.5m

Technical Parameters are subject to change without prior notice!

Our Services

Our Service
1.Installation Services
Installation Services are available with all new machine purchases. We will provide the technical know-how for your operation smooth transition and support for installing, debugging, operation of the machine, it will indicate you how to use this machine well.

2.Clients Traning Services
We can train your staff to use your equipment systems properly.It means that we offer Customers Training, teaching how to use the systems most efficiently and safely as well as how to maintain optimal operational productivity.

3.After Sales Service
We offer the Preventative Maintenance and After Sales Service. For we strongly feels about the importance of supporting our customers and the product solutions we provide.Consequently we offer comprehensive maintenance options to prevent equipment issues before they become problems. Also we offer one year guarantee period.

In one words,your satisfication is our persuit forever!
