Double Channel Fully Automatic T Shirt Bag Making Machine

Name: Double Channel Fully Automatic T Shirt Bag Making Machine
Brand: JINGDDIANRUIHUA
SKU: 112357219
Availability: InStock

US$ 9,000 - 20,000 MOQ: 1 Set

Key Specifications

Condition:

New

Machine Type:

Bag Forming Machine

Bag Type:

Shopping Bag

Ruian Ruihua Printing Packing Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo port/Shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Machine Type Bag Forming Machine

Bag Type Shopping Bag

Material Plastic

Computerized Yes

Place of Origin Zhejiang, China

Brand Name JINGDDIANRUIHUA

Model Number DGHQ-450*2

Voltage Single Phase 220V 50Hz

Power(W) 7Kw

Dimension(L*W*H) 6000*1400*1600mm

Weight 1500kgs

Certification CE SGS

Warranty One Year Guarantee Time

After-sales Service Provided Engineers available to service machinery overseas

Product Description

Specifications:
Use:
Double Channel Fully Automatic T Shirt Bag Making Machine is applied HDPE, LDPE,PP film rolls as raw material for plastic bag making. It is suitable for making different sizes vest bag,T-shirt bag with print or without print.
Main Technical Parameters:
Model	DGHQ-450×2
Max.Bag-making Width	400mm×2 lines
Max.Bag-making Length	650mm
Bag-making thickness	0.015-0.035mm
Bag-making Speed	2000-300pcs/min ×2 lines
Air Pressure	5kg/cm2
Specifications:
1. Double Channel Fully Automatic T Shirt Bag Making Machine is with PLC control, double step motor control, double photocell for tracking, double sealing knife for bag sealing and cutting, automatic punching system, automatic counting system
10. Double Channel Fully Automatic T Shirt Bag Making Machine can finish roll feeding, bottom sealing, bag cutting, hole punching and transmission in one process. It is high degree automatic and economic benefit machine for bag making.
