The introduction of household grid-tied photovoltaic power generation system:
Household grid-tied photovoltaic power generation system consists of photovoltaic modules, bracket, inverter, cables, circuit breaker, bidirectional meter, etc.
This system not only can generate electricity for private use,the surplus electricity can also be sold to the national grid.
The Installation location can be the roof or ground which is close to the users,which can avoid long distance transmission and can be applied at the point of use.It’s easy to install and the construction period is short.Besides,this system without noise and pollution.
structure diagram:
1) Solar Modules, 2)Inverter, 3) power distribution cabinet, ,4)Electrical load, 5)Grid
Main Characteristics:
1. High efficiency & high stability
2. Monocrystalline or Polycrystalline solar cells, range from 5Wp to 290Wp.
3. Unique frame design to reinforce sealing and there are drainage holes on the border components, eliminate the framework of deformation caused by rain or snow accumulated in the framework.
4. Strong aluminum frames to strengthen the load hold and to stand against high wind.
Special mounting holes on the frames suitable for long term mounting.
5. High transparency low iron tempered glass with enhanced stiffness and impact resistance property.
6. Advanced EVA encapsulation system with multi-layer back sheets to better product modules
7. Output tolerance: +/-5%, cell efficiency above 16%
8. Approvals: CE, IEC61215/61730, ISO, TUV
9. Back: TPT
10. Encapsulant :EVA
11. Frame: Aluminum alloy
12. Preeminent aesthetic appearance and easy installation
Our household grid-tied photovoltaic power generation system has 2 kw, 3 kw, 5 kw three series.The details are as follow.
System |
2KW |
Solar Modules |
Module Type: YZ- 240 Pm:250W,Vmp:37.8V,Imp:8.28A Size:1956mm*992mm*50mm Weight:19.0kg; Quantity :8 pieces |
Solar Panel Rack |
1 set |
Inverter |
Product model:Solarsoul 2000TL Quantity :1set Output:AC220V |
Cables |
Photovoltaic cable:4mm2,6 mm2 AC cable, BVVB (black):4mm2 |
Breaker |
2 pieces |
The bidirectional meter |
provided by SGCC(State Grid Corporation of China) |
System |
3kW |
Solar Modules |
Module Type: YZ- 240 Pm:250W,Vmp:37.8V,Imp:8.28A Size : 1956mm*992mm*50mm Weight :19.0kg; Quantity :12 pieces |
Solar Panel Rack |
1set |
Inverter |
Product model :Solarsoul 3000TL Quantity :1set Output :AC220V |
Cables |
Photovoltaic cable:4mm2,6 mm2 AC cable, BVVB (black):4mm2 |
Breaker |
2 pieces |
The bidirectional meter |
provided by SGCC(State Grid Corporation of China) |
System |
5kW |
Solar Modules |
Module Type : YZ-240 Pm:250W,Vmp:37.8V,Imp:8.28A Size : 1956mm*992mm*50mm Weight :19.0kg; Quantity :20 pieces |
Solar Panel Rack |
1set |
Inverter |
Product model :Solarsoul 5000TL Quantity :1set Output :AC220V |
Cables |
Photovoltaic cable:4mm2,6 mm2 AC cable, BVVB (black):4mm2 |
Breaker |
2 pieces |
The bidirectional meter |
provided by SGCC(State Grid Corporation of China) |
Terms and conditions:
1. Price: Shanghai Sunshine based on 10 sets.
2. Payment: 30% by T/T, balance by T/T before shipment. Other payment way can be negotiated for big order.
3. Package: Export standard package suitable for tough handling and sea transport.
4. Delivery: Goods to be ready within 10~325 days depending on order quantity.
5. Certification: CE,ROHS
Basic Information:
| Company Name: | Shanghai Sunshine Solar System Electric Co.,Ltd | |
|---|---|---|
| Year Established: | 2000 | |
| Business Type: | Manufacturer | |
| Main Products: | Portable Solar Panel Kit; Grid Tie Home Solar System;Car Power Inverter; Flat Solar Panel;Solar Roof Hook; Solar Street LED Lamp; Solar Inverter & Controller | |
| Other Products/Services: | solar backpack,solar power bag,solar case,portable battery | |
| Operational Address: | No.288 Tuanjie village Huinan Town,Pudong New Area,Shanghai,China (Mainland) | |
| Number of Employees: | 10-20 People View management | |
| Worker Staff: | 80-100 People | |
| No. of QA/QC Staff: | 10-15 People | |
| Management Certification: | CE & ISO 9001:2000 ISO 14001:2004 |
Warmly welcome your inquiry!
