Best Selling 5000w Pure Sine Wave Power Inverter

Best Selling 5000w Pure Sine Wave Power Inverter thumbnail-1
Best Selling 5000w Pure Sine Wave Power Inverter photo-1
US$ 1 - 50 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
SunShine
Model Number:
YN-X125000
Contact Supplier Request Quote Chat Now
Shanghai Sunshine Solar System Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name SunShine
Model Number YN-X125000
Output Power 401 - 600KW
Output Type Dual
Size 565*210*145mm
Weight 19kg/pc
Input Voltage 24V DC/48V DC
Output Voltage 100V~120V AC / 220V~240V AC
Type DC/AC Inverters
Output Frequency 50Hz or 60Hz

Solar inverter pure sine wave inverter 5000w

Factory directly supply&fast delivery.

*Frequency:50Hz or 60Hz



Best Selling 5000w pure sine wave power inverter



Model: YN-X125000

Remote control & LED digital  display

Hardwire Terminal Block



*Input volt: 24V DC/48V DC

*Output volt 100V~120V AC / 220V~240V AC

*Regulation: ± 5~10%

*Continuous power:5000W

*Surge power:10000W

*Low Voltage Alarm: 10.7V±0.3V DC / 21.4V±0.6V DC/ 42.8±1.2V DC

*Low Voltage Shutdown: 10.2V±0.3V DC / 20.4V±0.6V DC/40.8±1.2V DC

*High Voltage Shutdown: 15.5V±0.5V DC / 31V±1V DC/62±2V DC

*Temperature Protection: 65°C ±5°C

*Efficiency:>85%

*Frequency:50Hz or 60Hz

*No load current draw:  <1.5A

*Total Harmonic Distortion less than 3%

*Working Temperature: 0 ~ 40°C

*Working Humidity: 20%~80%

*Storage Temperature:  -30°C  ~ 70°C

*Product size:565*210*145mm

*Carton measurement:840X310X240mm,1pcs/ctn

*Load quantity:448pcs/20'





[Product Feature]
[1] Revolving speed of the fan intelligent control.
[2] Pulse Width Modulation(PWM).
[3] Soft start function.
[4] Overheat and overload automatically shut down. Will automatically start again after returning to normal.
[5] Input and output in a variety of ways:input 12V,24V .Cigarette lighter type,battery directly input. Output  voltage 220V AC 110V AC etc fully meet the needs of users at abroad on the AC Power.
[6] Products using aluminum alloy shell,high pressure plasma surface technology of itanium coating,high hardness,chemical stability,oxidation resistance,good appearance.

 Best Selling 5000w pure sine wave power inverter





Model  YN-X125000
Input  DC Voltage  12V or 24V or 48V or 110V
Voltage Range  10-15VDC or 21-30VDC or 42-60VDC or 100-120VDC
No Load Current Draw   < 1A
Efficiency  > 85%
DC Connector  Cables With Clips or Car Adaptor
Output  AC Voltage  100/110/120VAC or 220/230/240 VAC
Continuous Power  5000W
Surge Power  10000W
Waveform  Pure Sine Wave
Frequency  50Hz or 60Hz
AC Regulation  3%
Protection Low Voltage Alarm  10.7V±0.3V DC / 21.4V±0.6V DC/ 42.8±1.2V DC
Low Voltage Shut Down  10.2V±0.3V DC / 20.4V±0.6V DC/40.8±1.2V DC
Over Load   Shut Off Output
Over Voltage Shut Down  15.5V or 30.5V or 61.2V or 120V
Over Thermal Shut Off Output Automatically
Fuses Short Circuit
Environment  Working Temperature  Between -10°C and +50°C
Working Humidity  20%~90%RH non-condensing
Storage Temperature   Between -30°C and +70°C
Others Start Soft Start
Cooling Ways Cooling Fan
Total Harmonic Distortion THD < 5%

Pack Machine size(mm) 565*210*145mm
Packing Size(mm) 840X310X240mm
Net Weight(kgs) 17kg/pc
Gross Weight(kg) 18kg/pc
Packing Type

Carton packing







Please try to order sample or visiting in our factory , we trust it worth to do in long term business.







Best Selling 5000w pure sine wave power inverter
