160w 12v/18v folding solar panel/ foldable solar panel kit

Specifications

The most professional manufacturer of folding solar panel in China.
Very flexible and portable; Anodized aluminium frame

Good news! High efficiency solar panel charger 160w simples your life easily!





Light charging panel; solar camping panel outerdoor





A) Adopting high efficient crystalline silicon solar cells.

B) With whole set of accessories :Carry bag ,Controller,Cable(as customers' request), Alligator Clip,Connector and Supporting Leg,

C) suitable for home (lighting, TV and other electrical applicants)





Features:

1.160W  Monocrystalline silicon module consists of a series of monocrystalline silicon solar cells.
2.High-strength low-iron toughened glass, ageing-resistant EVA and complex film of good weather resistance are sequentially laminated to the module to make it high in light transmittance and mechanical strength.
3.Long life time: >=25 years, small attenuation.
4.by toughened glass of high light transmittance and high mechanical strength Adopting airtight , waterproof and multifunctional junction boxes to guarantee the safe of the module.
5.Good weather resistance, wind tightness and hail suppression. Preventing the panel from being  corroded by moisture and salt fog; unaffected by geographic environment.

6. Excellent performance under low light environments(mornings, evenings and cloudy days)

7.Withstand high wind and snow loads





Work:
Under normal lighting conditions, put the unfolded solar panel toward the sun direction, then red and black alligator clips touch positive and negative ends of the battery respectively. If the “Charge” light red and the “Load1” light green , it shows that the system is charging the battery normally . At the meantime , it can load ( 12V light or other electric appliances ) connect to the L + and L- .





Protection Function:
The solar controller have overcharge or undervoltage protection function for battery. When the charging voltage is higher than 14.4V , the controller will turn off charging  automatically ; When the battery voltage is lower than the protection voltage 10.8V , the controller turn off output automatically to protect the battery from damage . At the meantime , the digital light flash and it can’t charge .








Attention:
In the case of no load, do not connect the positive and negative.




Quality and Safety (CE&ISO approved):

A).Strict quality monitoring process,100% current and voltage.

B).Tests guarantee that the modules meet the power requirement.

C).Our modules have passed several international Certificates and tests

D).12 months on assembly,25 years on solar panel.











  Package Show: Packing is very solid!





We are professional in manufacturing solar modules.







Feel free to contact us!









Honest Is The Best Policy,We do quality &technology business.







Basic Information:

	Company Name:	Shanghai Sunshine Solar System Electric Co.,Ltd
	Year Established:	2000
	Business Type:	Manufacturer
	Main Products:	Portable Solar Panel Kit; Home Solar System; Solar Street LED Lamp; Flat Solar Panel;Solar Roof Hook
	Other Products/Services:	solar backpack,solar power bag,solar case,portable battery,solar inverter
	Operational Address:	No.288 Tuanjie village Huinan Town,Pudong New Area,Shanghai,China (Mainland)
	Number of Employees:	10-20 People View management
	Worker Staff:	80-100 People
	No. of QA/QC Staff:	10-15 People
	Management Certification:	CE & ISO 9001:2000 ISO 14001:2004
