Specifications
concrete mixerDimension: L*W*H (mm)=9970*2495*3790
Load Kg: 15000
Full load KG: 30530
Mix volume: (cbm): 7/10
Concrete Mixer Truck
| MAIN DESCRIPTION | |||
Overall Dimensions |
8810mm*2490mm*3800mm(L*W*H) |
||
Tare Weight |
11180kg |
Payload |
17500kg |
Front Overhang |
1500mm |
Rear Overhang |
2335mm |
Wheelbase |
3625mm+1350mm |
Track (F/R) |
2022mm/1830mm |
| CHASSIS | |||
Chassis Brand |
SINOTRUK HOWO |
||
Chassis Model |
ZZ1257M3641, driving type 6x4 |
||
Cab |
Standard HW70, left hand drive, air-conditioner, no sleeper |
||
Engine |
SINOTRUK WD615.87, 290hp, Euro II emission standard, 4-stroke direct injection diesel engine, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling, displacement 9.726L |
||
Gear Box |
FULLER9, No. of speeds: 9 forward & 1 reverse |
||
Traversing Mechanism |
German ZF8098, turning system pressure 18MPa |
||
Clutch |
GF420J, Single-plate dry clutch |
||
Rear Axle |
ST16 tandem axle, rated load 2x13ton, ratio 5.73 |
||
Wheels and tires |
Rim 8.5-20; tire 12.00-20, 10 units; Spare wheel carrier: with one spare wheel |
||
