Ductile Iron Mechanical Joint Pipe
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | VORTEX | |
| Model Number | ductile iron pipe | Length | 6m/5.7m | |
| Standard | ISO2531/EN545/EN598 | Application | water | |
| Diameter | DN80-DN2000 | Shape | Round | |
| Hardness | Max.230HB | Pipe Wall Thickness | 6.0-22.5mm | |
| Pull Strength | Min.420N/mm2 | Material | Ductile Iron | |
| Type | Other, centrifugal casting |
Product Description
Specifications
ISO 2531 C CLASS ductile iron pipe produced by vortex are with good quality and resonable price.EN545 ,EN598 all available .
1), Product Information
ISO 2531 ductile iron pipe manufactured by vortex are mainly used for transferring the drinkable water,waste water and for irrigation.
The diameter is from DN80-DN2000,K8/K9/K10/K12, Tyton socket and spigot,the standard length is 6m.
2),Standard
*conform to ISO2531/EN545/EN598/4179/8179
3), Material
* Ductile Iron GGG500-7&400-12 or ASTM-A-536grade 80-55-06
4) coating
* Metallic zinc spray with Bituminous Coating (Outside) Cement mortar lining (Inside). Epoxy coating available upon request.
5) joint method available
*Push-on
6), Process
* centrifugal casting
7), Inscription Style
* As per customers' requests
* Standard Inscription
8), Packing
* standard export bundle
* in bulk
* As per customers' requirements
9), Inspection
* Foundry in-house
* Third Party inspection available upon request
