Home > Products > Fasteners Machinery > WIRE NAIL MAKING MACHINES (Automatic, High Speed)(For Pop Rivet / Blind Rivet)
WIRE NAIL MAKING MACHINES (Automatic, High Speed)(For Pop Rivet / Blind Rivet)
- New Delhi
- T/T Money Gram Credit Card PayPal
You May Like
-
Solid / SEMI TUBULAR RIVETS Making Machine
-
Machine / Wood Screw Making Machine
-
Automatic High Speed Double Stroke Cold Heading Machines (Baby Model) For Pop Rivet & Solid Rivet Making
-
WIRE NAIL / PANEL PIN MAKING MACHINES (Automatic, High Speed)
-
Automatic Thread Rolling Machines (High Speed)
-
U Nail Making Machine
Product Details
| Place of Origin | Delhi, India | Brand Name | ABM | |
| Model Number | ABM-FM-6570 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
FEATURES
CONSTRUCTION
ABM TOOLS Panel Pin & Wire Nails making machines crank type are made from high grade castings and steel. Machines ensure perfect sturdy construction and long life.
DRIVE
Three shafts design has been adopted to ensure efficient smooth working. The main crank is direct operated by motor. The side shafts are driven by four bevel gears, which operate cutting tools. The separate shafts for cutting ensure correct adjustment of tools.
BEARING
Main crank & side shafts are fitted with special gun metal Bushes to ensure long life. All the Bushes & Lubricating Points are provided with cup type oil reservoirs.
WORKING OF MACHINE
The wire end from coil passes through straightening rollers and fed intermittently in the gripping dies, which close firmly allowing heading punch to press the head of the nails, then grip loosened and required length of the nail is fed constantly, where it is cut by cutting tools leaving ample stock for the head of the next nail. Thus ready nail is ejected by the ejector. The operations are repeated in each revolution.
WIRE FEED
The wire feed is obtained from main crank shaft. The desired length of nail is easy to set by adjustment bolt.
ACCESSORIES FOR THE PLANT
Grinding Machine, Polishing Drum and Spare Dies, etc.
SPECIFICATION (Wire Nail / Panel Pin Making Machine) | ||||||||||||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||||||||||||
SPECIFICATION (Wire Nail Making Machine) | ||||||||||||||||||||||||||||||||||||||||
|
