Home > Office Supplies > Presentation & Bulletin Board > Whiteboard > 95" Interactive Whiteboard Better Than Small Whiteboard
95" Interactive Whiteboard Better Than Small Whiteboard
US$ 289 - 450
MOQ: 3 Sets
Key Specifications
Get Latest Price
Whiteboard Type:
Interactive Whiteboard
Folded:
No
Brand Name:
Donview
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Donview All Sizes of Electromagnetic Interactive WhiteboardUS$ 380 - 900MOQ: 5 Pieces -
Multiuser Smart Board With Mobile Adjustable Stand and Projector Wall MountNegotiableMOQ: 1 Piece
-
Interactive Whiteboard and Wireless Writing Tablet for ClassroomUS$ 300 - 650MOQ: 1 Piece
-
Donview Smart Interactive Whiteboard for Teaching DeviceUS$ 280 - 380MOQ: 1 Set
-
Optimum Interactive Whiteboard Size for Small ClassUS$ 280 - 450MOQ: 1 Set
Whiteboard Type
Interactive Whiteboard
Folded
No
Brand Name
Donview
Model Number
DB-95EWS-D01
Place of Origin
China
Electromagnetic Interactive Whiteboard
Specifications :
| Model No. | DB-85ENS-D01 | DB-95EWS-D01 | DB-101EWS-D01 |
| Technology Principle | Passive phased array electromagnetic induction technology | ||
| Physical size(excluding DSP box) | 85"(1760mm×1296mm×43mm) | 96"(2078mm×1296mm×43mm) | 103"(2290mm×1296mm×43mm) |
|
Physical size (including DSP box) |
85"(1760mm×1296mm×71mm) | 96"(2078mm×1296mm×71mm) | 103"(2290mm×1296mm×71mm) |
| Effective writing area | 81"(1672mm×1190mm) | 91"(1990mm×1190mm) | 98"(2202mm×1190mm) |
| Relevant project size | 78"(1586mm×1190mm) | 88"(1904mm×1190mm) | 95"(2166mm×1190mm) |
| Resolution | 14100×10100 | 16800×10100 | 18600×10100 |
| Aspect Ratio | 4:3 | 16:10 | 16:9 |
| Net weight(kg) | 22KG ±2KG | 25KG ±2KG | 29KG ±2KG |
| Packing measurement | 1859×1389×120mm ±5mm | 2177×1389×120mm ±5mm | 2390×1389×120mm ±5mm |
| Gross weight(kg) | 31KG ±2KG | 34KG ±2KG | 39KG ±2KG |
| Pen | 300KHz Blue Pen | 300KHz Blue Pen | 300KHz Blue Pen |
| Pen holder | Capable with two pens | Capable with two pens | Capable with two pens |
Standard Features :
| Surface material | high-strength wear-resistant polymeric materials (Anti-dazzle PET), working life more than 5years. | ||
| Backing sheet material | ABS(Acrylonitrile Butadiene Styrene) engineering materials composite sheet | ||
| Frame material | Aluminum Alloy, processed with thermal spraying technology | ||
| Connection Interface | RJ45 net cable to USB | ||
| Data Transmission | Standard RJ45 network cable connection; not less than 10 meters, maximum up to 50 meters' distance transmission ability between computer and whiteboard . | ||
| Whiteboard Control module | The pluggable DSP circuit card is the only circuit parts inside the whiteboard. It supports hot-swapping, which greatly facilitates the maintenance. |
||
| Calibration pattern | Four kinds of precise calibration: 4 points, 5 points, 9 points and 16 points; error≤0.05mm | ||
| Response Time | 6ms; | ||
| Physical Shortcuts | 18 physical shortcuts which facilitate the operation of the users are listed on the left and right margin; Position: Horizontal centered on left and right margin of the board. Arrangement:(From the top) Whiteboard positioning; Switch to the mouse; New page; Prevpage; Next page; Blue ordinary pen; Red ordinary pen; Black ordinary pen; Yellow thick line highlighter; Smart brush; Eraser; cancel; Clear Screen; Text; Screen Capture; Open(insert); Visual Presenter; Soft keyboard; Model NO. also list under shortcuts |
||
| Special Features | Dust on the surface or on the frame of the board doesn't have any impact on the use of the whiteboard. | ||
| Sun shine irradiation has no impact on the use of the whiteboard. | |||
| Hand click or contact with the surface of the whiteboard will not cause misoperation. Working without noise, the writing noise ≤ 40dB. | |||
| The tip of the pen is made of POM and slicone oil that is abrasion-proof and smooth . The average life expectancy is 200,000 times (conventional writing strokes). The electronic pen is with the right mouse button function and a erase key. The structure of the pen body would avoid scroll. | |||
| Smooth Writing and sensitive response. The rapid response rate ensures continuous and rapid writing without delay and broken line. | |||
| OS Rquired | Windows XP,Vista,Win7. | ||
| Hardware Required | Equal with: CUP,intel Pentium 4 2.0 GHz, RAM 1GB, Video Memory 64MB & Free Hard disk space 20GB or higher |
||
| Power Supply | 5V | ||
| Power Consumption | Max: 0.8W | ||
| Operating Environment | Temperature:-10°C~50°C ; Relative Humidity:30%~80% | ||
| Storage Environment | Temperature:-25°C~70°C ; Relative Humidity:10%~90% | ||
| Installation | Default:Wall-mounted; Moble stand optional;Combined with blackboard in composite or rail type supported | ||
| warranty | Board Body: 3 years; Accessories: 1 year; Software: lifelong freely upgrade. |
||
| Certification Approved | ROHS, FCC, CE C-TICK | ||
| Manufacturer qualification | passed ISO9001 and ISO14001 certification,Identified as high-tech enterprises and software companies. | ||
