Donview all sizes of electromagnetic interactive whiteboard

Technical parameters and specification

Model

DB-85ENS-D01

DB-95EWS-D01

DB-101EWS-D01

Technology

electromagnetic induction technology

Board size(diagonal line)

85’’

95’’

103’’

Whiteboard specifications(length x high x ply)(mm)(not include CUP box)

1760×1296×43

2078×1296×43

2290×1296×43

Induction size(diagonal line)

81’’

91’’

99’’

Induction size(wide x high)(mm)

1672×1190

1990×1190

2202×1190

Effective projection size(diagonal line)

78’’

88’’

96’’

Effective projection size(wide x high)(mm)

1586×1190

1904×1190

2116×1190

Resolution

14100*10100

16800*10100

18600*10100

Screen Ratio

4:3

16:10

16:9

Whiteboard weight(kg)

22KG ±2KG

25KG ±2KG

29KG ±2KG

Shipping weight (kg)

31KG ±2KG

34KG ±2KG

39KG ±2KG

Pen tracking rate

6ms

Pen tracking rate

6ms

Shortcut

The two sides with 18 shortcuts, with picture and title

Board face material

Use the PET Panel material

Ways of connecting computer

USB to RJ45 connecter

Operating System

Windows XP,Vista,Win7

System demand

CPU Intel P4 Dual-core2.0G, RAM1G,display memery64M,Hard-disk space 20G;

Power supply

5v

Power Capacity

<2W

Operating Temperature

Temperature:-10°C-50°C Relative humidity 30%-80%

Storage temperature

Temperature:-25°C~70°C Relative humidity 10%-90%

Install method

Standard Configuration: handed on the wall (buy a stents from us can move)

Warranty service

Guarantee 3 years for the board body , 1 years for the accessories and freely upgraded for ever for the software

Products certificate

C-Tick, CE, HORS, FCC
