LRD Series Thermal Relay

LRD Series Thermal Relay thumbnail-1
LRD Series Thermal Relay photo-1
Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GWIEC
Model Number:
LRD series thermal solid state relay
Contact Supplier Request Quote Chat Now
Yueqing Geenwich Imp And Exp Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name GWIEC
Model Number LRD series thermal solid state relay
Theory Thermal Relay
Usage Auto
Size Miniature
Protect Feature Sealed
Contact Load Low Power







Product Description







LR-D series thermal relay is suitable for using in the circuits rated voltage up to 660V, rated current 93A AC 50/60Hz, for over-current protection of AC motor. The relay has the differentialmechanism and temperature compensation and can plug in CJX2N series AC contactor. Theproduct conforms to IEC60947-4-1 stardand.



  Model

  Rated Current

                       Thermal Component

Rated Current (A)

Current Setting Range

LRD13

                LRD1301

0.16

0.1~0.16

                LRD1302

0.25

0.16~0.25

                LRD1303

0.4

0.25~0.4

                LRD1304

0.63

0.4~0.63

                LRD1305

1.0

0.63~1.0

                LRD1306

1.6

1.0~1.6

                LRD1307

2.5

1.6~2.5

                LRD1308

4.0

2.5~4.0

                LRD1310

6.0

4.0~6.0

                LRD1312

8.0

5.5~8.0

                LRD1314

10.0

7.0~10.0

                LRD1316

13.0

9.0~13.0

                LRD1321

18.0

12.0~18.0

                LRD1322

24.0

17.0~25.0

                LRD1332

32.0

23.0~32.0

                LRD1335

38.0





LRD3322

25.0



LRD3353

32



LRD3355

40.0

30.0~40.0

LRD3357

50.0

37.0~50.0

LRD3359

65.0

48.0~65.0

LRD3361

70.0

55.0~70.0

LRD3363

80.0

63.0~80.0

LRD3365

93.0

80.0~93.0

LRD43

LRD4365

104.0

80.0~104.0

 LRD-4367

120.0

95.0~120.0

 LRD-4369

140.0

110.0~140.0





  LRD series thermal relay









Packaging & Shipping





1,Take 1 Pole as an example.

12 Pcs in 1 Carton,20 Cartons in 1 Box

2,In default,White blank Carton & Exporting 5-layer Hard Box

We can also design the Carton/Box according to your opinion
