Help CenterJR28-36 Thermal Overload Relay Hot LR2-D23
Related Products
-
3UA-61 GKJRS2 Thermal Overload RelayUS$ 1 - 50MOQ: 50 Pieces -
3UA-62 GKJRS2 Thermal Overload RelayUS$ 1 - 50MOQ: 50 Pieces
-
GK LRD13 Thermal Overload RelayUS$ 1 - 50MOQ: 100 Pieces
-
CJX1/3TF-32 16A AC Contactor From ChinaUS$ 1 - 10MOQ: 100 Pieces
-
3TF-51 140A AC ContactorUS$ 1 - 20MOQ: 20 Pieces
thermal Relay Application
This series of thermal overload relay can be used in the circuit of 50Hz or 60Hz, rated insulation voltage 660V, rated current 0.1-93A for protecting the phase break when the electric motor is overload.
The relay has different mechanism and temperature compensation & can be pluged in GKLC1-D series AC contactor. It is the most advanced thermal relay in the nineties in the world. The products comply with IEC 60947-5.
Characteristics
a. Fundamental parameter of the main circuit
(a). Rated insulation voltage 660V.
(b). Rated working current 25,36,93A separately.
(c). The regulator seal of rated setting current.
(d). Current of the Thermal component
b. Auxiliary Circuit
(a). There is one pair of N/O and N/C contact with electric insulation.
(b). Rated insulation Voltage 500V.
(c). Rated frequency 50-60Hz.
(d). Use group, rated working voltage, appoint thermal current and rated current.
| Type | Rated working current of thermal relay | Rated current(A) | Rated or scale of rated current(A) | |
| GKJR28-25 | 25 | GK LR2-D13 01 | 0.16 | 0.10~0.16 |
| GK LR2-D13 02 | 0.25 | 0.16~0.25 | ||
| GK LR2-D13 03 | 0.40 | 0.25~0.40 | ||
| GK LR2-D13 04 | 0.63 | 0.40~0.63 | ||
| GK LR2-D13 05 | 1.0 | 0.63~1.0 | ||
| GK LR2-D13 06 | 1.6 | 1.0~1.6 | ||
| GK LR2-D13 X6 | 2.0 | 1.25~2.0 | ||
| GK LR2-D13 07 | 2.5 | 1.6~2.5 | ||
| GK LR2-D13 08 | 4.0 | 2.5~4.0 | ||
| GK LR2-D13 10 | 6.0 | 4.0~6.0 | ||
| GK LR2-D13 12 | 8.0 | 5.5~8.0 | ||
| GK LR2-D13 14 | 10.0 | 7.0~10.0 | ||
| GK LR2-D13 16 | 13.0 | 9.0~13.0 | ||
| GK LR2-D13 21 | 18.0 | 12.0~18.0 | ||
| GK LR2-D13 22 | 25.0 | 17.0~25.0 | ||
| GKJR28-36 | 36 | GK LR2-D23 53 | 32.0 | 23.0~32.0 |
| GK LR2-D23 55 | 36.0 | 28.0~36.0 | ||
| GKJR28-93 | 93 | GK LR2-D33 53 | 32.0 | 23.0~32.0 |
| GK LR2-D33 55 | 40.0 | 30.0~40.0 | ||
| GK LR2-D33 57 | 50.0 | 37.0~50.0 | ||
| GK LR2-D33 59 | 65.0 | 48.0~65.0 | ||
| GK LR2-D33 61 | 70.0 | 55.0~70.0 | ||
| GK LR2-D33 63 | 80.0 | 63.0~80.0 | ||
| GK LR2-D33 65 | 93.0 | 80.0~104.0 | ||
