3UA-61 GKJRS2 Thermal Overload Relay

3UA-61 GKJRS2 Thermal Overload Relay thumbnail-1
3UA-61 GKJRS2 Thermal Overload Relay photo-1
US$ 1 - 50 MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GWIEC
Model Number:
GKJRS2-3UA-61
Contact Supplier Request Quote Chat Now
Yueqing Geenwich Imp And Exp Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name GWIEC
Model Number GKJRS2-3UA-61
Theory Thermal Relay
Usage General Purpose
Size Other
Protect Feature Other
Contact Load Low Power

Specifications



GKJRS2-3UA series thermal realy is suitabel for using in power system with AC 50HZ,rated operation voltage up to 660A and 1000V,in main circuit,current from 0.1A to 630A.It is used to protect AC threephase asynchronous motor against overload and open-phase.The realys have the best push-button for breaking NC contacts and the operating indication and free trip characteristiGK.The products also can be supplied with protecting case to ensure safety .The products can plug in the contactor and install independently or mount by rail.



Type

Rated insulation

 voltage(V)

    Rated working current

 of thermal relay(A)

Rated current

Rated(A)

 Rated or scale of rated current(A)
GKJRS2-63 660 63 3UA-59 0.16 0.1~0.16
0.25 0.16~0.25
0.4 0.25~0.4
0.63 0.4~0.63
1.0 0.63~1
1.25 0.8~1.25
1.60 1~1.60
2.0 1.25~2
2.5 1.6~2.5
3.2 2~3.2
4.0 2.5~4
5.0 3.2~5
6.3 4~6.3
8.0 5~8
10.0  6.3~10
12.5  8~12.5
16.0 10~16
20.0  12.5~20
25.0 16~25
32.0 20~32
40.0 25~40
45.0 32~45
57.0  40~57
63.0 50~63
GKJRS2-120 660 120 3UA-60 80.0 55~80
90.0  63~90
110.0  80~110
120.0  90~120
135.0  110~135
GKJRS2-150 660 150 3UA-61 80.0 55~80
90.0 63~90
110.0 80~110
120.0 90~120
135.0 110~135
150.0 120~150
GKJRS2-180 660 180 3UA-62 80.0 55~80
90.0 63~90
110.0 80~110
120.0 90~120
135.0 110~135
150.0 120~150
160.0 130~160
 180.0 150~180
GKJRS2-400 1000 400 3UA-66  125.0 80~125
 200.0 125~200
 250.0 160~250
 320.0 200~320
 400.0 250~400
GKJRS2-630 1000 630 3UA-68  500.0 320~500
 630.0 400~630

3UA-61 GKJRS2 Thermal Overload Relay

3UA-61 GKJRS2 Thermal Overload Relay

3UA-61 GKJRS2 Thermal Overload Relay

3UA-61 GKJRS2 Thermal Overload Relay



 3UA-61 GKJRS2 Thermal Overload Relay
