Home > Electrical & Electronics > Relay & Contactor > Relay > LR2-D33 THERMAL OVERLOAD RELAY 32A

LR2-D33 THERMAL OVERLOAD RELAY 32A

Name: LR2-D33 THERMAL OVERLOAD RELAY 32A
Brand: GWIEC
SKU: 112259379
Availability: InStock

LR2-D33 THERMAL OVERLOAD RELAY 32A thumbnail-1

LR2-D33 THERMAL OVERLOAD RELAY 32A photo-1

US$ 1.5 - 2 MOQ: 1000 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

GWIEC

Model Number:

LR2-D3353

Contact Supplier Request Quote Chat Now

Yueqing Geenwich Imp And Exp Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name GWIEC

Model Number LR2-D3353

Theory Thermal Relay

Usage Auto

Size Miniature

Protect Feature Sealed

Contact Load Low Power

Specifications

1.Thermal Relay, Protect Phase Break Relay
2.Rated Insulation Voltage: 660V
3.Rated Current(max): 93A
4.CE & Rohs

Description:

LR2 series of thermal relay can be used in the circuit of 50Hz or 60Hz, rated insulation voltage 660V, rated current 0.1 - 96A for protecting the phase break when the electric motor is overload. The relay has different mechanism and temperature compensation & can be plugged in kLCI-D series AC contactor.

Characteristice:

1. Fundamental parameter of the main circuit

Rated insulation voltage 660V.
Rated working current 25, 36, 93A separately.
The regulator seal of rated setting current and setting.
Current of the thermal component (see list 1)

2. Auxiliary circuit

There is one pair of NO/and N/C contact with electric insulation.
Rated insulation voltage 500V.
Rated frequency 50-60Hz.
Use group, rated working voltage, appoint thermal current and rated current.

Specification:

Type	Rated working current of thermal relay		Thermal component
Type	Rated working current of thermal relay		Rated current (A)	Rated or scale of rated current (A)
LR2-D13	25	LR2-D1301	0.2	0.10-0.16
		LR2-D1302	0.3	0.16-0.25
		LR2-D1303	0.4	0.25-0.40
		LR2-D1304	0.6	0.40-0.63
		LR2-D1305	1.0	0.63-1.0
		LR2-D1306	1.6	1.0-1.6
		LR2-D13X6	2.0	1.25-2.0
		LR2-D1307	2.5	1.6-2.5
		LR2-D1308	4.0	2.5-4.0
		LR2-D1310	6.0	4.0-6.0
		LR2-D1312	8.0	5.5-8.0
		LR2-D1314	10.0	7.0-10.0
		LR2-D1316	13.0	9.0-13.0
		LR2-D1321	18.0	12.0-18.0
		LR2-D1322	25.0	17.0-25.0
LR2-D23	36	LR2-D2353	32.0	23.0-32.0
LR2-D23	36	LR2-D2355	36.0	28.0-36.0
LR2-D33	93	LR2-D3353	32.0	23.0-32.0
		LR2-D3355	40.0	30.0-40.0
		LR2-D3357	50.0	37.0-50.0
		LR2-D3359	65.0	48.0-65.0
		LR2-D3361	70.0	55.0-70.0
		LR2-D3363	90.0	63.0-80.0
		LR2-D3365	93.0	80.0-93.0
