EOCR-SP1 / SP2 ELECTRONIC OVERLOAD RELAY
Negotiable
MOQ: 500 Parcels (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GIE
Model Number:
EOCR-SP1 / SP2
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
GIE
Model Number
EOCR-SP1 / SP2
Theory
Thermal Relay
Usage
General Purpose
Size
Miniature
Protect Feature
Sealed
Contact Load
Low Power
Specifications
1.EOCR-SP1 / SP2 RELAY2.Fundamental parameter of the main circuit
3.Auxiliary circuit
EOCR-SP1 / SP2 ELECTRONIC OVERLOAD RELAY
1).2 Integral Current Transformers
2).Fits Directly into IEC or NEMA Contactor
PROTECTION
| Protective Item | EOCR Operating (Trip) Time | |
| SP1 | SP2 | |
| Over-current | O-TIME(curve) | 5sec |
| Phase Loss | 4sec | 4sec |
| Locked Rotor | O-TIME+10sec | D-TIME |
| Time Characteris | Inverse | Definite |
SPECIFICATION
| EOCR | SP1 | SP2 | |
| Current Setting | 1 | 0.3 - 1.2A | 03 - 1.2A |
| 10 | 1 - 12A | 1 - 12A | |
| 20 | 5 - 25A | 5 - 25A | |
| Time | Start D-TIME | 10 sec(Fixed) | 1 - 50 sec |
| Setting | Trip O-TIME | 1~10 | 5 sec(Fixed) |
| Control Voltage | 110 | 85 - 150VAC | |
| (50/60Hz) | 220 | 180 - 260VAC | |
| Output Relay | Mode | 2-SPST | |
| Rating | 3A/250VAC Resistive | ||
| Status | Normally Energized | ||
| Time-Current Characteristic | Inverse | Definite | |
| Trip & Trip Cause Indication | 2-LED | ||
| Mount | Contactor Mounted | ||
