Home > Electrical & Electronics > Relay & Contactor > Relay > EOCR SS ELECTRONIC CURRENT OVERLOAD THERMAL RELAY

EOCR SS ELECTRONIC CURRENT OVERLOAD THERMAL RELAY

Negotiable MOQ: 500 Parcels (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

GIE

Model Number:

EOCR-SS

Contact Supplier Request Quote Chat Now

Yueqing Geenwich Imp And Exp Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name GIE

Model Number EOCR-SS

Theory Other, electronic overload relay

Usage General Purpose

Size Miniature

Protect Feature Sealed

Contact Load Low Power

Specifications

1.EOCR-SS RELAY
2.Fundamental parameter of the main circuit
3.Auxiliary circuit

EOCR SS OVERLOAD ELECTRONIC DIGITAL RELAY MOTOR PROTECTOR

1).2 Integral Current Transformers
2).Electronic Shear-pin Function
3).Independently Adjustable Starting
4).Trip Delay (D-Time) & Operating Time(O-TIME)

WIDE ADJUSTMENT RANGE
EOCR has a wide current adjustment range of over
10:1. It enables three type models to cover a wide
range from 0.1A up to 600A thus reducing the
number and type of relays that must be inventoried
for spare purposes.

LOOPING OPTION
Some motor size may require only one-third or
one-fourth of particular EOCR current range. These
installations can be accommodated by looping
the motor wire 2 or 3 times through the integral
current transformers of the EOCR. This reduces
the number and type of relays inventoried for
spare purposes. Each additional loop will increase
the current measured as indicated by the following
chart.

PROTECTION

Protective Item	Operating (Trip) Time
Over-current	O-TIME
Phase Loss	O-TIME
Locked Rotor	O-TIME + D-TIME

SPECIFICATION

Current setting	Type	Range
	5	0.5 - 6A
	30	3 - 30A
	60	5 - 60A
	100~(over 60A)	Ext. CT Option
Time	Start D-TIME	0.2 - 30 sec
Setting	Trip O-TIME	0.2 - 10 sec
Control Voltage	220	90 - 260VAC
(50/60Hz)	440	320 - 480VAC
Output Relay	Mode	1-SPDT(1C)
	Rating	3A/250VAC Resistive
	Status	Normally Energized
Time-Current Characteristic		Definite
Operating (Trip) Indication		2-LED
Mount		35mm Din-rail / Panel
