High Pressure water injection machine for oil fild
This product is the newly developed high pressure profile control pump.The fluid end of the product adopts combined split-type pump
head, with convenient dismantlement. Power end adopts integral rolling bearing-type transmission (between the crankshaft and the connecting rod), which is an ultra- strong power end, low noise and environmental protection product. It has low temperature rise, can operate 24h continuously, simple maintenance
and has a higher cost performance. It is a special product applied to surface subsidence of coal field, profile control disposal of oil field
and high-pressure and large capacity grouting.
Note: the product has obtained national patent.
Grouting Inlet Dimensions 3″
Grouting Outlet Inner DiameterØ34
Connection Dimensions M52×2
Stroke Length (mm) |
100 |
Plunger Diameter(mm) |
85 |
Number of Plungers |
// | 3 | / |
Motor Power(KW) |
90 | 110 | 132 |
Motor Speed(rpm) |
600-1340 | 650-1350 | 650-1350 |
Maximum Theoretical Capacity |
308 | 310 | 310 |
Rated Pressure |
13 | 18 | 22 |
Note: above parameters are theoretical data when the medium proportion is 1.0.
One-year warranty
Repairing and maintaining service is provided timely once received the inquiry, taking the customer satisfaction as first priority.
Service hotline & hotmail is provided for customers real time consulting.
Quality-related problem will be dealt with by professional staff at the first time getting the feedback from customers.
We provide on-site technical service at home and abroad.
