Help Center2014China TIME GO Reliable Bulk Cement Tank Semitrailer
Related Products
-
Container Semitrailer China Manufacture 2 Alxe 20ftUS$ 14,000 - 17,000MOQ: 1 Unit -
2014China TIME GO Brand Oil Tanker Semi Trailer for SalesUS$ 15,000 - 50,000MOQ: 1 Set
-
China Time Go 3 Axle 12 Twist Locks Skeleton Semi Trailer for SaleUS$ 12,000 - 13,200MOQ: 2 Units
-
Time Go 3axles 40m3 Dump Semi TrailerUS$ 30,000 - 35,000MOQ: 1 Unit
-
Side Wall Semitrailer 3alxe Best SellingNegotiableMOQ: 2 Units
Specifications
Use: Truck Trailer Type: Semi-Trailer Material: Steel Certification: ISO9001:2008, CCC Size: 12000*2490*3800 Max Payload: 60T
Main Dimensions | |
Tank Body | |
Shape |
Optional ( One Silo with V type or Two ,Three Silos Design) |
Dimension |
12000mm*2490mm*3990mm ( Exact size depends on the final design) |
Tare weight |
About 7500KGS-15000KGS |
Total Volume(m3) |
30m³-68 m³ |
Tanker Body Material |
5mm or 6mm/ Q235 carbon steel |
End Plate |
5mm or 6mm /Q235 carbon steel |
Diesel Engine |
WEICHAI ,Tianhe 4100/4102 or other brand |
Compressor |
BOHAI 10m³/12 m³or other brand |
Manhole Cover |
Cabon steel , diameter is 500mm |
Discharging Valve |
Diameter is 3 or 4 inch |
Discharging Pipe |
3 or 4 inch rubber hose, 1pcs, 6m/each |
Cat Walk |
With (Common model or special design) |
Chassis | |
Main Beams |
Weldding Design ,Q345 carbon steel |
Axle |
2 or 3 axles, 12T/13T/16T, BPW/FUWA/HUAJING brand |
Landing Gear |
JOST (D200T)or CHINA BRAND 28T |
King Pin |
JOST 2.00 or 3.5 inch bolt-in king pin |
Suspension |
Mechanical suspension/Germany or America type /Air Suspension |
Leaf Spring |
90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12 |
Pneumatic Braking System |
WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); 45L air tanks. |
Rim |
9.00-22.5/8.00-20/8.5-20 China Brand |
Tire |
12.00R22.5/315 80R22.5/11.00R20 /12.00R20 Brand can be Optional |
ABS |
Optional |
Painting |
Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
Accessories |
One standard tool box |
Shipping Terms |
By Bulk Cargo ,RORO |
