4-CH HDD Realtime Vehicle DVR Recorder
Specifications
1. 4-CH HDD realtime D1 vehicle DVR2. resolution: D1
3. can connect 4 cameras
4. safe lock, password
5. remote monitori
4-CH HDD realtime D1 resolution vehicle DVR--VR8800
Main Functions:
1. 4 channels record at the same tiem
2. D1 high clear network video server,NTSC:720*480/60fps; PAL: 720*576/54fps
3. adopt optimized MPEG-4 video condec, easy to realize high clear video transmission through low
bandwidth.
4. high claer audio output through adopt ADPCM compression condec.
5. support upto 1000GB SATA HDD
6. interface: one 10M/100M RT45
7. GPS & GPRS optional
8. advanced network transmission server technique, realize multi-users visit.
9. mult-users managent via password
10. support local real-time video surveillance output.
11. support PAL/NTSC composite video input.
12. cober lock and password to keep data safty.
13. data cannot be deleted unless formating, which need password.
Parameters
| Model | VR8800G (4-CH HDD DVR) |
| Working Voltage | DC 8-36 V(DC 14-36 V when power camera) |
| Maximum Current | ≤2.5 A |
| Working Temprature | –10°C~50°C |
| Output Voltage(for camera) | DC12 V |
| Power Supply | Car battery |
| Maximum Memory Capacity | 1000 GB |
| CompressionFile Format | MPEG2/MPEG4 |
| Record Switch | Continuous record or motion detect |
| Record mode | Motion detect,schedule and manual record |
| Record Quality | 3 rating adjustable |
| Resolution | D1 (PAL 720*576,NTSC 720*480) |
| Frame Rate | PAL(1~54fps optional) |
| NTSC(1~60fps optional) | |
| Record AV in signal | 4 CH video+2 CH audio |
| File Store Mode | Overwrite when full or stop when full |
| Internet Interface | One 10M/100M RJ45 |
| Alarm output | Can connect alarm with audio and light |
| HDD Interface | One 2.5″SATA HDD interface |
| Compatible camera | Common CMOS & CCD |
| Dimension | 194mm ×180mm×50mm |
| Net weight | 2.2 KG |
