Help Center4-CH HDD 3.5"LCD Realtime D1 Resolution Moveable DVR
Related Products
-
4CH HDD Full D1 Resolution DVRUS$ 130 - 135MOQ: 5 Pieces -
4 Channels Full D1 Standalone Mobile DVRUS$ 130 - 135MOQ: 20 Pieces
-
4-CH Realtime D1 Resolution GPS HDD DVRUS$ 195 - 220MOQ: 20 Pieces
-
4ch Full d1 Real Time H.264 Format Mobile Dvr With ce and Fcc CertificationUS$ 115 - 130MOQ: 1 Unit
-
4 Channels Real Time Full d1 Mobile Dvr for Car, Bus, Lorry,taxiUS$ 115 - 130MOQ: 1 Unit
Specifications
1. 4-CH HDD realtime moveable DVR2. 3.5" LCD
3. can power 4 cameras directly
4. safe lock, password
5. remote monitoring
4-CH HDD 2.5"LCD realtime D1 resolution DVR--VR8800
Functions:
1. VR8800 can provide DC 12V to four cameras directly. No need extral power adapter for cameras,
which will save you 5 DOLLORS.
2. compatible with any CCD or CMOS cameras, as long as it's working power is DC 12V.
3. VR8800 is especially designed for vehicle, all the connectors are anit-vibration ones.
4. 16 cusions to protect HDD from shake.
5. Immediately get into the "preview mode(ready to record)" once power on.
6. Can use remote control, which makes operation much more convenient for user.
7. Power on/off delaying to protect HDD.
8. All files will be saved in HDD, they won't be lost if power went off suddenly.
9. Comopatable with any CCD OR CMOS camera.
10. can connect and power 4 cameras directly, 4 channels can be recorded synchronously.
11. 2.5" SATA HDD, maximum support upto 1000GB.
12. with 3.5" high definite TFT.
13. D1 resolution, NTSC:720*480/60fps; PAL: 720*576/50fps
14. adopt optimized MPEG-4 video condec, easy to realize high clear video transmission through
low bandwidth.
15. RJ45 interface, realize remote monitoring and multi-users visit.
16. mult-users managent via password
17. support local real-time video surveillance output.
18. support PAL/NTSC composite video input.
19. safe lock, pass word, special software keep data safe.
20. motion detection optional.
21. pre-record, schedule record optional.
22. online upgrade is avaliable.
23. data download via USB port.
Parameters
| Model | VR8800G (4-CH HDD DVR) |
| Working Voltage | DC 8-36 V(DC 14-36 V when power camera) |
| Maximum Current | ≤2.5 A |
| Working Temprature | –10°C~50°C |
| Output Voltage(for camera) | DC12 V |
| Power Supply | Car battery |
| Maximum Memory Capacity | 1000 GB |
| CompressionFile Format | MPEG2/MPEG4 |
| Record Switch | Continuous record or motion detect |
| Record mode | Motion detect,schedule and manual record |
| Record Quality | 3 rating adjustable |
| Resolution | D1 (PAL 720*576,NTSC 720*480) |
| Frame Rate | PAL(1~54fps optional) |
| NTSC(1~60fps optional) | |
| Record AV in signal | 4 CH video+2 CH audio |
| File Store Mode | Overwrite when full or stop when full |
| Internet Interface | One 10M/100M RJ45 |
| Alarm output | Can connect alarm with audio and light |
| HDD Interface | One 2.5″SATA HDD interface |
| Compatible camera | Common CMOS & CCD |
| Dimension | 194mm ×180mm×50mm |
| Net weight | 2.2 KG |
