Specifications
1. 4-CH HDD vehicle tracking DVR2. 3.5" LCD
3. can power 4 cameras directly
4. safe lock, password
5. remote monitoring
4-CH HDD vehicle tracking DVR--VR8800GP
Main functions:
1. With GPS and GPRS function, realized accurate vehicle tracking.
2. Powerful and easy operate software. With our software, you can manage 500pcs of VR8800GP, which means that you can track 500pcs of vehicles by our software. It is easy to operate.
3. two tracking molds: real time tracking and historical tracking. Once the vehile engine is started, VR8800GP will send data to tracking center every ten senconds.
4. Vehicle can be tracking by using cell phone. VR8800GP will send data to your cell phone if you called it. Match the data which is send by VR8800GP to google e-map you know where exactly the vehicle is.
5. Adopt anti-vibration design. All connectors are anti-vibration. There are 12 small cushions to protect the HD. It can work normally if the road is bumpily. All data are safe in hard disk.
6. Immediately get into the "preview mode(ready to record)" once power on.
7. Can use remote control, which makes operation much more convenient for user.
8. Power on/off delaying to protect HDD.
9. All files will be saved in HDD, they won't be lost if power went off suddenly.
10. Comopatable with any CCD OR CMOS camera.
11. can connect and power 4 cameras directly, extral powr for cameras do not needed, which will not only save you a few dollars, but also save you from the troublesome cables. 4 channels can be recorded synchronously.
12. 2.5" SATA HDD, maximum support upto 1000GB.
13. with 3.5" high definite TFT.
14. D1 resolution, NTSC:720*480/60fps; PAL: 720*576/50fps
15. adopt optimized MPEG-4 video condec, easy to realize high clear video transmission through low bandwidth.
16. RJ45 interface, realize remote monitoring.
17. mult-users managent via password
18. can match with PAL and NTSC video system.
19. safe lock, pass word, special software keep data safe.
20. multiple record modes can be set on main meau for different hours: motion detection, schedule record, pre-record and manual record.
21. online upgrade is avaliable.
22. data download via USB port.
23. with a low power consumption fan to cooling down the unit.
Parameters
| Model | VR8800G (4-CH HDD DVR) |
| Working Voltage | DC 8-36 V(DC 14-36 V when power camera) |
| Maximum Current | ≤2.5 A |
| Working Temprature | –10°C~50°C |
| Output Voltage(for camera) | DC12 V |
| Power Supply | Car battery |
| Maximum Memory Capacity | 1000 GB |
| CompressionFile Format | MPEG2/MPEG4 |
| Record Switch | Continuous record or motion detect |
| Record mode | Motion detect,schedule and manual record |
| Record Quality | 3 rating adjustable |
| Resolution | D1 (PAL 720*576,NTSC 720*480) |
| Frame Rate | PAL(1~54fps optional) |
| NTSC(1~60fps optional) | |
| Record AV in signal | 4 CH video+2 CH audio |
| File Store Mode | Overwrite when full or stop when full |
| Internet Interface | One 10M/100M RJ45 |
| Alarm output | Can connect alarm with audio and light |
| HDD Interface | One 2.5″SATA HDD interface |
| Compatible camera | Common CMOS & CCD |
| Dimension | 194mm ×180mm×50mm |
| Net weight | 2.2 KG |
