Universal & Precise Cutter and Tool Grinder

Universal & Precise Cutter and Tool Grinder thumbnail-1
Universal & Precise Cutter and Tool Grinder thumbnail-2
Universal & Precise Cutter and Tool Grinder thumbnail-3
Universal & Precise Cutter and Tool Grinder thumbnail-4
Universal & Precise Cutter and Tool Grinder thumbnail-5
Universal & Precise Cutter and Tool Grinder thumbnail-6
Universal & Precise Cutter and Tool Grinder photo-1
Universal & Precise Cutter and Tool Grinder photo-2
Universal & Precise Cutter and Tool Grinder photo-3
Universal & Precise Cutter and Tool Grinder photo-4
Universal & Precise Cutter and Tool Grinder photo-5
Universal & Precise Cutter and Tool Grinder photo-6
US$ 1,155 - 1,364 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
MEIRI MACHINE TOOLS
Model Number:
MR-600F
Contact Supplier Request Quote Chat Now
Taizhou Meiri Machine Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai/ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name MEIRI MACHINE TOOLS
Model Number MR-600F
Condition New

Specifications

1. Universal tool grinder
2.With high precision straight line roiling guide rails, high stability, dexterous operation.
3.CE

Universal & Precise Cutter and Tool GrinderUniversal & Precise Cutter and Tool Grinder



The working table uses high precision straight line roiling guide rails,good back and forth movement, high stability, steady bed platform, dexterous operation.

Motor can rotate 360°in the horizontal plane, the grinding wheel can be clockwise and anticlockwise rapidly. When grind different kinds of material's cutter, you can turn the grinding wheel, which can add the safety and reduce the time of replacing and dressing the grinding wheel, adding controllability of cutter grinding.
1. Standard accessory can grind lathe tool, face and side cutters, hobbing cutters, circular paper cutters,etc.
2. Choosing 50E accessory can grind MO-type 4# coning spiral milling cutter, ball cutter, R-shape lathe tool,etc

3. Choosing 50K accessory can grind MO-type 4# coning or diameter 3-32mm drill bit, screw tap, etc.

4. Choosing 50D accessory can grind MO-type 4# coning spiral milling cutter, etc.
5. Choosing 50J thimble, 50B toolbox and so on.
 Universal & Precise Cutter and Tool Grinder

/watch?v=twOC0DI6m6Y



Model:

MR-600F

About worktable Diameter:

300mm

About worktable travelin schedule:

150mm

Worktable area:

130×520mm

Rotating Angle of Wheel head:

360°

Grinding wheel size:

125×50×32mm

Power/Speed:

2800 RPM

Motor:

3/4HP  220V/380V

Dimension:

700×630×630mm

Weight:

175kg/160kg

Standard Equipment:

50C,50H can grind slot miller,face and side cutter,lathe tool ,hobbing cutter,reamer bit etc.

Option Equipment:

50E grind spiral milling cutter ball end mill,R type lathe tool,graver and other taper milling cutter.

50K can grind drill bit ,screw tap,side mill,round bar and so on.

50D can grind end mill ,side mill and so on.

50B tablebox

50J thimble

Universal & Precise Cutter and Tool GrinderUniversal & Precise Cutter and Tool GrinderUniversal & Precise Cutter and Tool GrinderUniversal & Precise Cutter and Tool GrinderUniversal & Precise Cutter and Tool GrinderUniversal & Precise Cutter and Tool Grinder
