Shantui 10Ton Forklift With Forkift Covers and Air Conditioner

Shantui 10Ton Forklift With Forkift Covers and Air Conditioner thumbnail-1
Shantui 10Ton Forklift With Forkift Covers and Air Conditioner photo-1
US$ 28000.00 - 29000.00 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
SHANTUI
Contact Supplier Request Quote Chat Now
Shandong Volin Heavy Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shanghai/Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name SHANTUI
Model Number SF100
Type Powered Pallet Truck
Power Souce Diesel Engine
Rated Loading Capacity 10000kg
Max. Lifting Height 6000mm
Min. Lifting Height 3000mm
Fork Length 1220mm
Fork Width 175mm
Overall Dimensions 5400x2230x2800mm
Certification ISO9001/ISO14001/CE
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Product Advantages

Shantui10.0Ton diesel forklift (SF100)equipment with Original Japanese ISUZU 6BG1 engine, hydraulic transmission,double oil pump,hydraulic assisted steering,front double tires.It is widely used to handing all kinds of goods,such as pallet,steel,brick etc.Shantui has cooperated with KOMATSU more than 30 years,all the product was made under KOMATSU standard.





Engine
Model
ISUZU 6BG1

Rated Output
82.4/2000
Kw/rpm
Rated Torque
415/1500
N·m/rpm
No.of cylinder
6

Bore×stroke
105x125
mm
Displacement
6.5
L


Dimensions
Lifting Height
3000
mm
LxWxH(With/Without Fork)
5400(4180)x1995x2500
mm
Turning radius
3540
mm
Mast tilt angle(F/R)
6/12
Degree


Performance
Travel speed(full load/no load)
20/25
Km/h
Lift speed (with /without) load
360/400
mm/sec
Max.gradeability
20
%
Self weight
12700
Kg


Wheel&tires
Front
9.00-20-14PR

Rear
9.00-20-14PR

Wheelbase
2800
mm
Min.ground clearance(mast)
240
mm
Detailed Images

Original ISUZU 6BG1 Engine.

Original from Japan,best choice for 5-10Ton diesel forklift.Strong Power,low oil consuption.

Air Conditioner

When the forklift working,the temputure will be very high,You can choose a AC inside the Cabin.

Heater for optional

To protect the operater warm working in cold area.Shantui equipmented with a heater inside the Cabin.

Double Oil Pump.

To keep the hydraulic system working at the best condition,using a double oil pump.

Good quality Hydraulic Valve.

Choose the best Hydraulic Valv supplier in China.

LED Displaly Instrument.

Easy reading LED instrument,you can get the information of oil temperature,fuel level,working hours.

Working Performance
Packing & Delivery
Shipping
By Container,2 sets per 40 feet high container,mast disassembled,canbe shipment by Ro-Ro Ship.
Packing
Nude Packing,Four tires fixed
No. of packets
Forklift    1  set            Fork     2   pcs.                Tool box   1 Set
Measurement
26CBM
Weight
12700KGS
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
