High Quality Aluminite Powder Ball Mill

Specifications

a) Aluminite Powder Ball Mill
1).Easy and safe operation
2).Stable performance
3).high working efficiency

     Aluminite Powder Ball Mill



Ball mill organization character :

      By feeding department, the exiting material department, the rotor, the transmission department (speed reducer, small transmission gear, electrical machinery, electric control) and so on main part composes .The midlevel axis uses the steel casting, the inside lining is detachable, rotates the big wheel to use the casting to roll the tooth processing, tube in vivo besets with by the wear-resisting backing, has the good resistance to wear. It revolves steadily, operation reliable.
Note: According to material and emissions mine  type , may choose the dry Aluminite Powder Ball Mill and the wet check ball mill.

ball mill grinding features
1.Easy maintenance and operation;
2.Big crushing ratio, uniform end product size;

Ball Mill Grinding application

Aluminite Powder Ball Mill is an efficient machine for fine powder grinding which is widely used in the manufacturing industries, such as cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics.

Ball Mill Grinding structures

The machine is composed by feeding part, discharging part, rotation part and driving part (reducer, small driving gear, electric motor and electric control).

high-efficiency ore dressing ball mill with ISO9001-2008

A ore dressing Aluminite Powder Ball Mill, a type of grinder, is a cylindrical device used in grinding (or mixing) materials like ores, chemicals, ceramic raw materials and paints. Ball mills rotate around a horizontal axis, partially filled with the material to be ground plus the grinding medium.
Different materials are used as media, including ceramic balls, flint pebbles and stainless steel balls. An internal cascading effect reduces the material to a fine powder. Industrial ball mills can operate continuously, fed at one end and discharged at the other end. Large to medium-sized Aluminite Powder Ball Mill are mechanically rotated on their axis, but small ones normally consist of a cylindrical capped container that sits on two drive shafts (pulleys and belts are used to transmit rotary motion).
Size
The smaller the media particles, the smaller the particle size of the final product. At the same time, the grinding media particles should be substantially larger than the largest pieces of material to be ground.
Density
The Aluminite Powder Ball Mill  media should be denser than the material being ground. It becomes a problem if the grinding media floats on top of the material to be ground.
Hardness
The grinding media needs to be durable enough to grind the material, but where possible should not be so tough that it also wears down the tumbler at a fast pace.
Composition
Various grinding applications have special requirements. Some of these requirements are based on the fact that some of the grinding media will be in the finished product. Others are based in how the media will react with the material being ground.
Where the color of the finished product is important, the color and material of the grinding media must be considered.

Flammable products have a tendency to become explosive in powder form. Steel media may spark, becoming an ignition source for these products. Either wet-grinding, or non-sparking media such as ceramic or lead must be selected.
Some media, such as iron, may react with corrosive materials. For this reason, stainless steel, ceramic, and flint grinding media may each be used when corrosive substances are present during grinding.

Techinical Parameter of Ball Mill
