8ports 10Gigabit Ethernet Switch 10Gigabit Data Center Switch

8ports 10Gigabit Ethernet Switch 10Gigabit Data Center Switch thumbnail-1
8ports 10Gigabit Ethernet Switch 10Gigabit Data Center Switch thumbnail-2
8ports 10Gigabit Ethernet Switch 10Gigabit Data Center Switch thumbnail-3
8ports 10Gigabit Ethernet Switch 10Gigabit Data Center Switch thumbnail-4
8ports 10Gigabit Ethernet Switch 10Gigabit Data Center Switch thumbnail-5
8ports 10Gigabit Ethernet Switch 10Gigabit Data Center Switch thumbnail-6
8ports 10Gigabit Ethernet Switch 10Gigabit Data Center Switch photo-1
8ports 10Gigabit Ethernet Switch 10Gigabit Data Center Switch photo-2
8ports 10Gigabit Ethernet Switch 10Gigabit Data Center Switch photo-3
8ports 10Gigabit Ethernet Switch 10Gigabit Data Center Switch photo-4
8ports 10Gigabit Ethernet Switch 10Gigabit Data Center Switch photo-5
8ports 10Gigabit Ethernet Switch 10Gigabit Data Center Switch photo-6
US$ 700.00 - 910.00 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Products Status:
Stock
Ports:
Other, ≤ 8
Transmission Rate:
10/100/1000Mbps
Contact Supplier Request Quote Chat Now
Shenzhen Smartlink EC Industrial Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Ports Other, ≤ 8
Transmission Rate 10/100/1000Mbps
Function LACP, QoS, SNMP, VLAN Support
Communication Mode Full-Duplex
Certification CE ROHS
Switch Capacity 460Gbps
Brand Name Samoxmei
Model Number SL-ES6600-15XF-8
Place of Origin Guangdong, China
Product Description

Smartlink SL-ES6600-15XF-8 10Gigabit Data Center Switch is standard layer 3+ non-blocking switch. Providing 460Gbps switching capacity and 352.36Mbps forwarding performance, L2 / L3 full wire-speed forwarding; flexible networking capability ensures the stability of the network and the balance of the load link. With the modular design, it provides 15 10G SFP+ optical ports, 1 1G SFP+ Optical port, 8 10/100/1000M RJ45 electrical ports, 1 Console port, 1 OOB management port, which offers enough bandwidth for data aggregation and data exchange. And in order to flexibly respond to the network requirements, users can select appropriate 10G ports according to their needs.

Features
1 .High density 10G access, performance is remarkable
With 460Gbps backplane bandwidth, the industry the highest performance (1U TOR);
Hardware routing, wire speed packet rate reached 352.36Mbps, L2 / 3 forward full speed;
15 10G SFP+ optical ports, the industry the highest density (1U TOR), satisfies the requirement of server 10G access;
8 10/100/1000M RJ45 electrical ports, industry the only high density 10G switches provide more 1G port access.
2 . Wind direction flexible choice, green and energy saving
Adopt strict before and after air duct design and support the hot and cold air duct is completely isolated, improve heat efficiency, satisfies the requirement of data center computer room design
Through selecting fan and power supply module, flexible support before, during and after the first air duct;
Support power supply and fan redundancy configuration, ensure continuous business operation;
Innovative energy-saving technology: using the latest energy-saving chip, fan speed control scheme of intelligent, supports real-time detection power consumption, reduce operational cost for the customer, create green data center.
3.Convenient in operation and maintenance
Support XModem protocol, use TFTP/ZMODEM to software upgrading and BootRom upgrading;
support SFP+, also backwards compatible XFP
To provide redundant power supplies,quick failover and fast connection, greatly increase the system reliability.
Specification
Model No
SL-ES6600-15XF-8
Chipset
Broadcom BCM53416 * 1 + BCM50280 * 1
Basic characteristics
Fixed port
15 10G SFP+ optical ports, 1 1G SFP+ Optical port, 8 10/100/1000M RJ45 electrical ports
Memory capacity
512MB DDR3 SDRAM
Console port
1
OOB management port
1
Backplane bandwidth
460Gbps
Packet forwarding rate
352.36Mpps
Jumbo frames
16356 bytes
Transfer mode
Support store-forward mode and cut-through mode
I Pv4/IPv6 router
6K/8K
MAC address table
96k
Packet Buffer
4MB
VLAN ID
4K
Flash memory capacity
16MB
Soft Specification
Security Features
IP+MAC+PORT+VLAN binding
ARP inspection
DOS defend
Port protect
IP Source Guard binding
VLAN
Port based VLAN
802.1Q VLAN
IP based VLAN
MAC based VLAN
MAC address table
Static MAC address table
Dynamic MAC address table
Storm Control
Broadcast suppression
Multicast suppression
DLF suppression
Limiting rate
Traffic Control
Half-duplex control based on the back pressure type
Full-duplex control based on the PAUSE frame
Port Mirror
Support port mirror
Port management
General setting
Port counting
Config port
Port trunk
Port-isolation
QoS
IEEE 802.1Q Congestion mechanism
Each port has 8 send queue mapping to 8 802.1p priority
IP services
Ping detection
DHCP Snooping
Spanning Tree Protocol
MSTP(802.1s)、STP、RSTP
Multicast management
IGMP Snooping frame
System management
Support SNMP v1/v2/v3
Support Console
Support TELNET
Support WEB
Remote Upgrade
Support version upgrading via web Support version upgrading via local
Physical characteristics
Power Supply Features
  AC: 90V～290V DC: -38.4V～-72V
Power
≤100W
Indicator light
Power indicator, system, connection/sending and receiving instructions
Environment
Humidity / Temperature
Operating temperature: 0°C～50°C (0m～1800m) ;
Storage temperature: -40°C～+70°C;
Relative humidity: 5%RH～95%RH, Non-condensing.
Certificate
European Community (CE) Electromagnetic Compatibility Directive：
This equipment has been tested and found to comply with the protection requirements of European Emission Standard EN55022/EN60555-2 and the Generic European Immunity Standard EN50082-1.
EMC:
EN55022(1988)/CISPR-22(1985)，class A EN60555-2(1995)，class A
EN60555-3
IEC1000-4-2(1995)，4K V CD, 8KV, AD
IEC1000-4-3(1995)，3V/m
IEC1000-4-4(1995)，1KV – (power line), 0.5KV – (signal line)
Federal Communications Commission (FCC) :
This equipment has been tested and found to comply with the limits for a class A computing device pursuant to Subpart J of part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment.
