bucket wheel stone washing machine,dashan hot selling
- 150 Set / Sets per Month
- shanghai qingdao tianjin
- T/T L/C D/P D/A
- Mining Stone Crushing Machine Silica Quartz Sand Making Production Line
- High Efficiency Stone Fine Crusher 5X Series Sand Making Machine
- High Efficient Artificial Building VSI Crusher Sand Making Machine Equipment
- Automatic Zero Discharge Concrete Recycling System
- Concrete Batching Plant Parts
- Concrete Recycling Machine
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | DASHAN |
Model Number: | XL,XSD series | Voltage: | 15kw | Dimension(L*W*H): | refer to the specifications |
Weight: | 5-15t | Certification: | CE,ISO | Warranty: | 1 year, 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Place of Origin:CN;HEN; Brand Name:dashan ; Certification:CE & ISO9001; Condition;New; Name; bucket wheel stone washing machine;
Characteristics of bucket wheel stone washing machine:
Reasonable structure,
large capacity,
low consumption,
little loss of the sand during the washing process,
low failure rate.
Introduction of bucket wheel stone washing machine;
bucket wheel stone washing machine is widely used in gravel pits, mining, building materials, transportation, chemical industry, water utilities, concrete mixing stations and other industries in the washing of the material. bucket wheel stone washing machine can be divided into two types: GX type and XL type. It can remove the impurities covered the surface of sand and gravel, while damage to the water vapor coated the layer of sand to facilitate the dehydration, plays washing sand cleaning role.
Application of bucket wheel stone washing machine;
bucket wheel stone washing machine is widely used in particle a New type stone washing machine ggregate sand screw washing, grading and dehydrating quartz and sand in construction site, sand stone factories, hydropower station and concrete dam site, precast concrete factory, glass factory and etc. It is especially applicable to wash construction sand and paving sand. This sand washing plant has the features of reliable structure, convenient maintenance, big capacity, low power consumption, high cleaning level. The new sealing structure, totally closed oil bath type drive device and adjustable overflow weir plate promises that the machine works efficiently.
Working Principle of bucket wheel stone washing machine:
The electric motor runs slowly with the impellor after decelerated by the belt, decelerator and gears wheel. The sand and stone flow into washing launder from feeding launder, rolls with the impellor, and grinds each other. The impurity covering the sand is washing away. At the same time, add more water, the strong water flow will take away waste and some low-weight wastes from washing launder. Through the above process, the washing function is finished. The clean sand and stone is lift up by vane. When it goes up slowly, the water begins to drop through the mesh and fall back in the washing launder. On one hand, water is removed from the sand and stone; on the other hand, the water can be fully used. Finally, the sand and stone goes to the out launder from the rotary impellor to finish the washing task.
Technical parameters of bucket wheel stone washing machine;
Models | Wheel Size (mm) | Max feed size (mm) | Power (Kw) | Weight (t) | Capacity (t/h) | Overall dimension (mm) |
XSD2610 | Φ2600×1000 | 10 | 5.5 | 2.7 | 50 | 3255×1982×2690 |
XSD2816 | Φ2800×1000 | 10 | 11 | 3 | 100 | 3540×3000×2880 |
XSD3016 | Φ3000×1600 | 10 | 15 | 3.3 | 150 | 3845×3000×3080 |
scenes of workshop;
international cooperation;
customer site;
