Help CenterTFR7800W 112dBuV Output Optical Receiver
Related Products
-
TFR7800W Small AGC Optical ReceiverNegotiableMOQ: 1 Set -
TFR7800W 112dBuV AGC Optical ReceiverNegotiableMOQ: 1 Set
-
TFR7800W High Output Level Optical ReceiverNegotiableMOQ: 1 Set
-
TON6800K Advanced ATT-pad Adjustment Technique Optical NodeNegotiableMOQ: 1 Set
-
TON6800K 1G AGC Optical NodeNegotiableMOQ: 1 Set
Specifications
power range is at 1~ -6dBmsingle output level up to 108dBuV
GaAs output amplify module
Optical AGC,SNMP
1 or 2 output port
Features
- Perfect surge suppression circuit, improved the anti-thunder stroke and surge impact prevention ability
- The input stage adopt imported low noise GaAs amplifier, the output stage adopt imported CATV GaAs high performance module, improved C/N and the non-line distortion characteristic greatly, simultaneously reduced the power consumption
- Strict reliability test, MTBF is longer than 100,000 hours
- Excellent optic detector: responsibility > 0.9 A/W, light alarm instructions when input power too low
- RF output level and slope are adjustable. Output port 1-2 are available, tap/splitt are available.
- Reserve international standard network interface, easy to field upgrade
- Optical AGC function,the output level changed within ±0.5dB, while input power changed at +1dBm~-6dBm
Brief
TFR7800W optical receiver can be used for CATV network, digital network and telecom network, especially suitable for optical fiber extends to the building, connect to subscriber’s home directly.
TFR7800W Optical receiver power range is at 1~ -6dBm. When receiver input power at 0dBm, and dual outputs, each RF output level up to 104dBuV; single output level up to 108dBuV; when optical receiver power at -5dBm, C/N > 49dB.
~220V power-supply modes are available, the high-performance transforms circuit become + 24V, + 5V straight to optical receiver internal devices.
Technique Parameter
Project |
Unit |
Performance |
note |
||
Optic |
wavelength |
nm |
1290~1560 |
|
|
Optical connectors |
|
FC/APC or SC/APC |
|
||
Input power range |
dBm |
1~-6 |
|
||
Input power indicate voltage |
mW/V |
1.0±10% |
|
||
RF |
Frequency range |
MHz |
47~860 |
|
|
Flatness |
dB |
±0.75 |
|
||
RF ports number |
|
1~2 |
Tap/split output are available |
||
Standard output power(at input power 1~ -6dBm) |
dBuV |
108 |
Single output |
||
104 |
Double output |
||||
Impedance |
Ω |
75 |
|
||
Gain adjusting range |
dB |
0~20 |
Adjustable continuously |
||
Slope adjusting range * |
dB |
0~18 |
1dB step |
||
Output return loss |
dB |
>16 |
860MHz bandwidth range |
||
Link |
C/N |
dB |
>50 |
Optical receiver power at-3dBm,single output power at 104dBuV |
|
CTB |
dBc |
>65 |
|||
CSO |
dBc |
>62 |
|||
General |
Dimension |
mm |
170×138×46 |
|
|
voltage |
Vac |
220 |
|
||
Power Consumption |
VA |
<15 |
|
||
working temperature |
°C |
-25~+55 |
|
||
Storage temperature |
°C |
-25~+65 |
|
||
Weight |
Kg |
0.5 |
|
||
note: *means Pre-EQ is 4dB, example; EQ plug is 5 dB , then output EQ 4 + 5 = 9 dB | |||||
