Vertical Multistage Pump
1. APPLICATION:
Mainly used for circulation and boost of both cold and hot pure waters in a high pressure moving system, water supply with pumps in parallel in a high building, the water supply and cooling system of fire-fighting and boilers and the transporting of various rinsing liquids.
2. FEATURES:
1). The GDL Multistage Pipeline Centrifugal pump uses a vertical, sectional and stainless steel casing structure to have both inlet and outlet on a same level;
2). The vertical multi-stage pump has less land area, high efficiency, nice appearance, light weight and small noise at running; and the pump features a high efficiency, energy-saving, stable running, etc. Beside, the multistage centrifugal pump uses the wearable mechnical seal, thus it is no leak and a long duration of use;
3). There are the stainless steel of various brands avaliable for choice.
3. RANGE OF PERFORMANCE:
Item |
Data |
Capacity |
6---1650m3/h |
Head |
24---150m |
In-out Diameter |
25---150mm |
Liquid Temperature |
-15---120°C |
Operating Pressure |
≤2.5Mpa |
Rotate Speed |
2900r/min |
4. STRUCTURE DRAWING OF GDL MULTISTAGE CENTRIFUGAL PUMP
5. ATLAS STYLE AND PERFORMANCE DATA
6.CE CERTIFICATE
Other Pumps:
Company Introduction
Shanghai Bangpu Industrial Group Co., Ltd. is a group enterprise specializing in the research and production of various fluid transfer equipments. Our main products include pumps,valves,motors,electric series and water supply system package. Waste water treatment, environmental protection equipments, accessories are also within our main business area. In 2008, Bangpu Group acquired Shanghai Electrical Machinery Factory Co., Ltd. and embarked on a higher speed growing path.
