Help CenterOpen Frame Touch Monitor With Metal Case and Frameless Design for Industrial Applications(10.2inch,12.1 Inch)
Related Products
-
GREENTOUCH Waterproof Touch Screen Monitor, Cheap Touch Screen Monitor 17 InchUS$ 1 - 300MOQ: 1 Piece -
12.1 Inch Open Frame LCD Touch Monitor ; POS Machine ; POS SystemUS$ 1 - 300MOQ: 1 Piece
-
Green Touch Waterproof Touch Screen Monitor15 Inch LCD Cheap Touch Screen Monitor and Touch MonitorUS$ 1 - 300MOQ: 1 Piece
-
Led Backlight 19 Inch Open Frame Touch Monitor With VGA AV HdmiUS$ 1 - 300MOQ: 1 Piece
-
Newest 15 Inch Lcd Advertising Monitors,open Frame Touch MonitorUS$ 1 - 300MOQ: 1 Piece
Specifications
All in one touch monitorHD resolution high contrast ratio fast response wide angle
adapted with worse environment
VGA
Product specifications and parameters:
GreenTouch Open Frame Monitor adopt new A + LCD screen produced by international companies, designed withall-plasticergonomic shell, and new energy-saving drive board . Special for desktop anddesktop public service inquiry system,POS systems, hotel reception, self-service, industrial manufacturing, information systems and other interactive touch applicationsenvironmental design .
Open frame touch monitor specifications and parameters:
| Model Number | GT-TMO150A |
| Display type | TFT LED panel |
| Screen Ratio | 16:10 |
| Resolution | 1680X1050 |
| Active area | 475X292(mm) |
| Brightness | 300cd/m2 |
| Contrast Ratio | 1000:1 |
| Support color | 16.7M |
| Response time | 8ms |
| Pixel Pitch | 0.297x0.297mm |
| Viewing Angle | Horizontal(L/R):85°/85° Vertical(Up/Down):80°/80° |
| Video input | DVI,VGA |
| Scan Frequency | Horizontal:30~80KHz ,Vertical: 56.3~75Hz |
| Power Input | Support AC 100 ~ 240V,50 ~ 60Hz,DC12V-3A |
| Environment | Operating temperature:0 to 50°C Storage temperature:-20 to 60°C |
| Operating humidity:20% to 80% Storage humidity:10% to 90% | |
| Mean Time Between Failure (MTBF) | 30,000 hours |
| Backlight working life(Typ.) | 50,000 hours |
| Touch screen Type | 4/5 wire resistive,SAW,IR Optical touch screen (can be selected) |
| Touch life | Over 5,00 million times |
| Touch object | Finger or touch pen |
| Touch screen interface | USB or RS232 interface |
| Power consumption | Max 30W |
| Certificates | CE, FCC |
| Button | POWER,MENU,AUTO,UP,DOWN |
| Warranty | 1 year |
Open frame touch monitor pictures
Open frame touch monitor Certificates
Open frame touch monitor shipping and payment
And also accept by Sea ,Air .or sending with your own forwarder
Shipping Days
DHL/UPS/Fedex : about 3 ~7working days
EMS/ TNT : 5-10 working days
1.Hong Kong Post Air Mail/ Hong Kong Post Air Parcel : 7 to 30 days
Notes: Yours goods will be dispatched within 3 business days immediately the payment has been confirmed. If your payment fails, the order will be closed automatically.
2. We are not responsible for any insurance or damage which is caused during shipping. Besides, buyers are responsible for the possible customs duty or tax charged by the local customs officers.
Return and Warranty Policy
1. All the goods are carefully inspected before shipping, so if you are not satisfied with them after you’ve receive them, you can exchange the items in one week . Therefore you have to contact us as soon as possible.
2. The shipping and handling charge is not refundable and the customer should be responsible for all the charges of the returning and reshipping
3. All return items much be packed in its original conditions, including box and accessories, Men made defects are not guaranteed, such as broken, scratched and so on.
4. For any items, please send by EMS or your local post when sent back.
Open frame touch monitor, why choose ours?
1.Professional manufacturer in R&D, manufacturing, marketing and service of TOUCH SCREEN for 8 years.
2.High quality certificate (CE,ROHS,FCC) Our products have aging test at least for a continuous 48-72hours before being deliveried.
3.Product warranty for 1-4 years.
4.Sufficient stock for your urgent demand. 5.Within 12 hours reply guarantee.
Open frame touch monitor company show
Hope to set up friendly business relationship with all of you.Your comments on our products and any information from your market will be highly appreciated.
(If I'm off line, would you send a massage to me or email please ? i will reply within 12hours .)
