Rotating the Forklift Attachment
1.Functions&Applications:
WONTONNE rotator used for rotating the forklift attachment ,it is widely used in food processing,agriculture,recycling,automotive manufacturing,and general manufacturing operations where bins or tobe boxes are used for both dumping and general handling requirements.
2.Features:
180°Rotation Stop Group:used when stopping rotation at precisely 180° is desirable.
Rotational Torque:High torque motor,ensures smooth,positive rotation of the load.
Forks Rotators can be ordered with standard forks,customizable forks or without forks.
3.Specifications
|
Capacity / Load Center |
Catalog Order No. |
Truck/ Rotator Mounting Class |
Rotator/ Fork Mounting Class |
Fork Length |
Carriage Width |
Fork Max. Spacing |
Overall Width |
Vertical Center of Gravity |
Weight |
Effective Thickness |
Horizontal Center of Gravity |
| A | B | OTO | C | CGV | ET | HCG | |||||
| (kg@mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (kg) | (mm) | (mm) | |||
| 1700@500 | RRB20D-001A | II | II | NO | 815 | 705 | 840 | 320 | 188 | 127 | 56 |
| 2200@500 | RRB20D-006A | II | II | NO | 815 | 705 | 840 | 300 | 300 | 150 | 79 |
| 3000@500 | RRB30D-008A | II | II | NO | 940 | 855 | 965 | 270 | 313 | 150 | 81 |
| 3000@500 | RRB30D-008B | III | II | NO | 940 | 855 | 965 | 290 | 329 | 191 | 114 |
| 3000@500 | RRB30D-009A | II | II | NO | 1145 | 1060 | 1170 | 265 | 327 | 150 | 84 |
| 3000@500 | RRB30D-009B | III | II | NO | 1145 | 1060 | 1170 | 285 | 343 | 191 | 117 |
| 3500@500 | RRB35D-010B | III | III | NO | 1065 | 990 | 1090 | 290 | 390 | 201 | 124 |
| 3500@500 | RRB30D-011B | III | III | NO | 1220 | 1140 | 1245 | 290 | 406 | 201 | 127 |
| 5400@500 | RRB50D-002B | III | III | NO | 1525 | 1418 | 1550 | 330 | 513 | 163 | 91 |
| 5400@500 | RRB50D-002C | IV | III | NO | 1525 | 1418 | 1550 | 275 | 565 | 221 | 137 |
| 5400@500 | RRB50D-004C | IV | IV | NO | 1550 | 1420 | 1590 | 395 | 783 | 173 | 99 |
| 6800@600 | RRB70D-001C | IV | IV | NO | 1245 | 1245 | 1285 | 415 | 924 | 218 | 119 |
4.Packages
