Ultra Thin Wall Heat Shrink Tube Supplier's Choice
USD $0.01 - $9.99
/ Meter
1000 Meters(Min.Order)
- 1000 Ton / Tons per Month
- Dalian China
- T/T Credit Card
You May Like
-
water clear thin wall cross-linked polyolefin shrink tubing
-
Halogen free think wall cross-linked polyolefin for General purpose
-
Polyvinylidene fluoride PVDF heat shrinkable tubing
-
VW-1 Kynar thin wall heat shrink tube
-
Identification heat shrink sleeve
-
Military grade heat shrink UV protection sleeve for markers
Product Details
| Place of Origin | Liaoning, China | Brand Name | UPM | |
| Model Number | S2(s) | Type | Insulation Sleeving | |
| Material | PE | Application | Low Voltage | |
| Rated Voltage | 1kV | Tensile Strength | 25MPa |
Product Description
Specifications
Ideal for wire harness bundling,cable labeling, wire terminal insulatin and protection
| S2(s) Ultra Thin Wall Heat Shrink Tube | ||||
| Features | ||||
| Light weight & flexible | Operating temperature: -40~90 ℃ | |||
| Ultra thin wall cross-linked polyolefin | Shrink temperature: 90 ℃ | |||
| High Flame retardant VW-1 | Shrink Ratio:2:1 & 3:1 | |||
| Low shrink temperature | Voltage Class:300V | |||
| Rapid shrinking | RoHS Compliant | |||
| Technical Data | ||||
| Property | Test method | Values | ||
| Physical | Density | -- | 1.15~1.25 | |
| Thermal endurance | -- | 125℃ | ||
| Tensile strength | When test at 500mm/min. | ≥10.4 MPa | ||
| Breakdown elongation | When test at 500mm/min. | ≥ 200% | ||
| Aging(158 ℃/168hrs) | Tensile strength | When test at 500mm/min. | ≥ 7.3 MPa | |
| Breakdown elongation | When test at 500mm/min. | ≥ 100% | ||
| Heat shock | 4hrs. at 200℃ | No cracking, drop or flow | ||
| Cold bend | 1 hour at -30℃ | No cracking | ||
| Water absorption 24h at 23℃ | -- | ≤0.5% | ||
| Electrical | Dielectric breakdown voltage | -- | ≥ AC 2500V | |
| Dielectric withstand voltage | 1min.AC2500V | No breakdown | ||
| Aging(158 ℃/168hrs) | Dielectric breakdown voltage | -- | AC 2500V min. and more than 50% of the value obtained with unaged sample | |
| Dielectric voltage Withstand | 1min.AC2500V | No breakdown | ||
| Volume resistivity | -- | ≥1014 Ω.cm | ||
| Chemical | Copper stability | 168h at 158℃ 500mm/min. | Elongation≥100% | |
| Flammability | VW-1 | UL224 | ||
| Note: The test methods conform to UL224. | ||||
| Typical application | ||||
| Ideal for wire harness bundling, cable labeling, wire terminal insulation and protection. | ||||
| Suitable for the temperature-sensitive electronic component that requires rapid shrinking | ||||
| Ordering | ||||
| Standard color : Yellow and White. | ||||
| Standard packaging on spools. | ||||
| Please specify specification, color, quantity when ordering | ||||
| Cross reference | ||||
| Raychem/Tyco : Versafit V4 | ||||
| Dimensions | ||||
| Reference | As supplied(mm) | After recovered(mm) | Standard length | |
| UPM S2(s) | ID | ID max. | WT nom. | m/spool |
| Shrink ratio: 2:1 | ||||
| 1.0 | 1.4±0.2 | 0.65 | 0.20 | 200 |
| 1.5 | 1.9±0.2 | 0.85 | 0.20 | 200 |
| 2.0 | 2.4±0.2 | 1.00 | 0.22 | 200 |
| 2.5 | 2.9±0.2 | 1.30 | 0.25 | 200 |
| 3.0 | 3.4±0.2 | 1.50 | 0.28 | 200 |
| 3.5 | 3.9±0.2 | 1.80 | 0.28 | 200 |
| 4.0 | 4.4±0.2 | 2.00 | 0.30 | 200 |
| 4.5 | 4.9±0.2 | 2.30 | 0.30 | 100 |
| 5.0 | 5.5±0.2 | 2.50 | 0.32 | 100 |
| 6.0 | 6.5±0.2 | 3.00 | 0.32 | 100 |
| 7.0 | 7.5±0.3 | 3.50 | 0.32 | 100 |
| 8.0 | 8.5±0.3 | 4.00 | 0.32 | 100 |
| 9.0 | 9.5±0.3 | 4.50 | 0.35 | 100 |
| 10.0 | 10.5±0.3 | 5.00 | 0.35 | 100 |
| 11.0 | 11.5±0.3 | 5.50 | 0.40 | 100 |
| 12.0 | 12.5±0.3 | 6.00 | 0.40 | 100 |
| 13.0 | 13.5±0.3 | 6.50 | 0.40 | 100 |
| 14.0 | 14.5±0.3 | 7.00 | 0.40 | 100 |
| 15.0 | 15.5±0.4 | 7.50 | 0.40 | 100 |
| 16.0 | 16.5±0.4 | 8.00 | 0.40 | 100 |
| 17.0 | 17.5±0.4 | 8.50 | 0.40 | 100 |
| 18.0 | 18.5±0.4 | 9.00 | 0.42 | 100 |
| 20.0 | 20.5±0.5 | 10.00 | 0.45 | 100 |
| 22.0 | 22.5±0.5 | 11.00 | 0.45 | 100 |
| 25.0 | 25.5±0.5 | 12.50 | 0.45 | 50 |
| Shrink ratio: 3:1 | ||||
| 3/1 | 3 | 1 | 0.56 | 200 |
| 6/2 | 6 | 2 | 0.58 | 100 |
| 9/3 | 9 | 3 | 0.60 | 50 |
| 12/4 | 12 | 4 | 0.61 | 50 |
| 15/5 | 15 | 5 | 0.62 | 50 |
| 18/6 | 18 | 6 | 0.63 | 25 |
| 24/8 | 24 | 8 | 0.64 | 25 |
| ID=Internal Diameter | WT= wall thickness | |||
