Halogen Free Think Wall Cross-linked Polyolefin for General Purpose
US$ 0.01 - 9.99
MOQ: 1000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Liaoning, China
Brand Name:
UPM
Model Number:
S2(n)
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Polyvinylidene Fluoride PVDF Heat Shrinkable TubingNegotiableMOQ: 1 -
VW-1 Kynar Thin Wall Heat Shrink TubeUS$ 0.01 - 99MOQ: 200 Meters
-
Identification Heat Shrink SleeveNegotiableMOQ: 100 Meters
-
Military Grade Heat Shrink UV Protection Sleeve for MarkersNegotiableMOQ: 1000 Meters
-
Supper Thin Wall Heat Shrink Tube for Covering Fluorescent LampUS$ 0.01 - 99MOQ: 500 Meters
Place of Origin
Liaoning, China
Brand Name
UPM
Model Number
S2(n)
Type
Insulation Sleeving
Material
PE
Application
Low Voltage
Rated Voltage
1kV
Tensile Strength
10.4MPa
Specifications
Highly flame retardant, flexible heat shrinkable tubing with environmentally friendly halogen free formula.| S2(n) Halogen Free Thin Wall Cross-linked Polyolefin for General Purpose | ||||
| Features | ||||
| Insulation, Protection,Identification | Operating temperature: -40~125 ℃ | |||
| Flame retardant VW-1(except clear) | Shrink temperature: 125 ℃ | |||
| Halogen free, Flexible | Shrink Ratio:2:1 & 3:1 | |||
| Wide range of colors | Voltage Class:600~1000 V | |||
| Approvals | ||||
| UL approval | File No.: | |||
| Technical Data | ||||
| Property | Test Method | Values | ||
| Physical | Density | -- | 1.25~1.35 | |
| Thermal endurance | -- | 125℃ | ||
| Tensile strength | When test at 500mm/min. | ≥10.4 MPa | ||
| Breakdown elongation | When test at 500mm/min. | ≥ 200% | ||
| Aging(158 ℃/168hrs) | Tensile strength | When test at 500mm/min. | ≥ 7.3 MPa | |
| Breakdown elongation | When test at 500mm/min. | ≥ 100% | ||
| Heat shock | 4hrs. at 250℃ | No cracking, drop or flow |
||
| Cold bend | 1 hour at -30℃ | No cracking | ||
| Water absorption 24h at 23℃ | -- | ≤0.5% | ||
| Halogen free | IEC 61249-2-21 | Cl:900ppm max. Br:900ppm max.Total (Cl + Br) : 1500ppm max. | ||
| Electrical | Dielectric breakdown voltage | -- | ≥ AC 2500V | |
| Dielectric withstand voltage | 1min.AC2500V | No breakdown | ||
| Aging(158 ℃/168hrs) | Dielectric breakdown voltage | -- | AC 2500V min. and more than 50% of the value obtained with unaged sample | |
| Dielectric voltage Withstand | 1min.AC2500V | No breakdown | ||
| Volume resistivity | -- | ≥1014 Ω.cm | ||
| Chemical | Copper stability | 168h at 158℃ 500mm/min. | Elongation≥100% | |
| Flammability | VW-1 | UL224 | ||
| Note: The test methods conform to UL224. | ||||
| Shrink ratio 3:1 | ||||
| Reference | As supplied(mm) | After recovered(mm) | Standard length | |
| UPM S2(n) | ID min. | ID max. | WT nom. | m |
| 1.5/0.5 | 1.5 | 0.5 | 0.5 | 200 |
| 3.0/1.0 | 3.0 | 1.0 | 0.7 | 200 |
| 4.5/1.5 | 4.5 | 1.5 | 0.7 | 100 |
| 6/2 | 6.0 | 2.0 | 0.8 | 100 |
| 9/3 | 9.0 | 3.0 | 1.0 | 50 |
| 12/4 | 12.0 | 4.0 | 1.1 | 50 |
| 15/5 | 15.0 | 5.0 | 1.2 | 50 |
| 18/6 | 18.0 | 6.0 | 1.3 | 50 |
| 24/8 | 24.0 | 8.0 | 1.5 | 25 |
| 30/10 | 30.0 | 10.0 | 1.7 | 25 |
| 39/13 | 39.0 | 13.0 | 1.9 | 25 |
| 50/16 | 50.0 | 16.0 | 2.5 | 1 |
| 60/20 | 60.0 | 20.0 | 2.6 | 1 |
| 70/23 | 70.0 | 23.0 | 2.6 | 1 |
| 80/26 | 80.0 | 26.0 | 2.8 | 1 |
| 90/30 | 90.0 | 30.0 | 2.8 | 1 |
| 100/33 | 100.0 | 33.0 | 3.0 | 1 |
| Dimensions | |||||||||
| Shrink ratio 2:1 | |||||||||
| Reference | As supplied ID (mm) | After recovered(mm) | Standard length | Reference | As supplied ID(mm) | After recovered(mm) | Standard length | ||
| UPM S2(n) | ID max. | WT | m/spool | UPM S2(n) | ID max. | WT | m/spool | ||
| 0.6 | 0.9±0.2 | 0.4 | 0.33±0.10 | 200 | 15.0 | 15.5±0.4 | 7.5 | 0.70±0.10 | 100 |
| 0.8 | 1.1±0.2 | 0.5 | 0.33±0.10 | 200 | 16.0 | 16.5±0.4 | 8.0 | 0.70±0.10 | 100 |
| 1.0 | 1.5±0.2 | 0.7 | 0.36±0.10 | 200 | 17.0 | 17.5±0.4 | 8.5 | 0.70±0.10 | 100 |
| 1.5 | 2.0±0.2 | 0.9 | 0.45±0.10 | 200 | 18.0 | 19.0±0.5 | 9.0 | 0.70±0.10 | 100 |
| 2.0 | 2.5±0.2 | 1.0 | 0.45±0.10 | 200 | 20.0 | 22.0±0.5 | 10.0 | 0.80±0.15 | 100 |
| 2.5 | 3.0±0.2 | 1.3 | 0.45±0.10 | 200 | 22.0 | 24.0±0.5 | 11.0 | 0.80±0.15 | 100 |
| 3.0 | 3.5±0.2 | 1.5 | 0.45±0.10 | 200 | 25.0 | 26.0±0.5 | 12.5 | 0.90±0.15 | 50 |
| 3.5 | 4.0±0.2 | 1.8 | 0.45±0.10 | 200 | 28.0 | 29.0±0.5 | 14.0 | 0.90±0.15 | 50 |
| 4.0 | 4.5±0.2 | 2.0 | 0.45±0.10 | 200 | 30.0 | 31.5±1.0 | 15.0 | 1.00±0.15 | 50 |
| 4.5 | 5.0±0.2 | 2.3 | 0.45±0.10 | 100 | 35.0 | 36.5±1.0 | 17.5 | 1.00±0.15 | 50 |
| 5.0 | 5.5±0.2 | 2.5 | 0.56±0.10 | 100 | 40.0 | 41.5±1.0 | 20.0 | 1.00±0.15 | 50 |
| 5.5 | 6.0±0.2 | 2.8 | 0.56±0.10 | 100 | 45.0 | ≥45 | 22.5 | 1.10±0.15 | 25 |
| 6.0 | 6.5±0.2 | 3.0 | 0.56±0.10 | 100 | 50.0 | ≥50 | 25.0 | 1.10±0.15 | 25 |
| 7.0 | 7.5±0.3 | 3.5 | 0.56±0.10 | 100 | 60.0 | ≥60 | 31.0 | 1.20±0.20 | 25 |
| 8.0 | 8.5±0.3 | 4.0 | 0.56±0.10 | 100 | 70.0 | ≥70 | 36.0 | 1.20±0.20 | 25 |
| 9.0 | 9.5±0.3 | 4.5 | 0.56±0.10 | 100 | 80.0 | ≥80 | 41.0 | 1.30±0.20 | 25 |
| 10.0 | 10.5±0.3 | 5.0 | 0.56±0.10 | 100 | 90.0 | ≥90 | 46.0 | 1.30±0.20 | 25 |
| 11.0 | 11.5±0.3 | 5.5 | 0.56±0.10 | 100 | 100.0 | ≥100 | 51.0 | 1.30±0.20 | 25 |
| 12.0 | 12.5±0.3 | 6.0 | 0.56±0.10 | 100 | 120.0 | ≥120 | 61.0 | 1.30±0.20 | 25 |
| 13.0 | 13.5±0.3 | 6.5 | 0.70±0.10 | 100 | 150.0 | ≥150 | 76.0 | 1.30±0.20 | 25 |
| 14.0 | 14.5±0.3 | 7.0 | 0.70±0.10 | 100 | 180.0 | ≥180 | 91.0 | 1.30±0.20 | 25 |
| ID=Internal Diameter | WT= wall thickness | ||||||||
| Typical application | |||||||||
| Ideal for electrical insulation,strain relief,wire bonding and light harness jacketing | |||||||||
| Common applications include electronic systems of subway, aircraft, submarine | |||||||||
| , control room facilities and sealed environment | |||||||||
| Ordering | |||||||||
| Standard color : Red,Blue, Yellow, Green, Black, Clear | |||||||||
| Special colors are available on request | |||||||||
| Spools as standard, cutting pieces or assorted kits available on request | |||||||||
| Please specify specification, color, quantity when ordering | |||||||||
| Cross reference | |||||||||
| Raychem/Tyco : Versafit V2 / RNF-100 | |||||||||
