water clear thin wall cross-linked polyolefin shrink tubing

Name: water clear thin wall cross-linked polyolefin shrink tubing
Brand: UPM
Availability: InStock

FOB Price

USD $0.01 - $9.99 / Meter

1000 Meters(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Insulation protection , Identification

S2VC Very Clear Thin Wall Crosslinked Polyolefin Shrink Tubing
Features
Insulation, Protection,Identification		Operating temperature: -55~125 ℃
Voltage Class:600-1000 V		Shrink temperature: 125 ℃
Halogen free, Flexible		Shrink Ratio:2:1 & 3:1

Technical Data
Property		Test Method		Values
Physical	Density	--		0.95
	Thermal endurance	--		125℃
	Tensile strength	When test at 500mm/min.		≥25 MPa
	Breakdown elongation	When test at 500mm/min.		≥ 450%
Aging(158 ℃/168hrs)	Tensile strength	When test at 500mm/min.		≥ 20 MPa
Aging(158 ℃/168hrs)	Breakdown elongation	When test at 500mm/min.		≥ 350%
	Water absorption 24h at 23℃	--		≤0.5%
	Heat shock	4hrs. at 250℃		No cracking, drop or flow
	Cold bend	4hrs at -55℃		No cracking
	Halogen free	IEC 61249-2-21		Cl : 900ppm max. Br : 900ppm max. Total (Cl + Br) : 1500ppm max.
	Halogen free	IEC 61249-2-21
Electrical	Dielectric breakdown voltage	--		≥ AC 2500V
	Dielectric voltage Withstand	1min.AC2500V		No breakdown
Aging(158 ℃/168hrs)	Dielectric breakdown voltage	--		AC 2500V min. and more than 50% of the value obtained with unaged sample
	Dielectric breakdown voltage	--
	Dielectric voltage Withstand	1min.AC2500V		No breakdown
	Volume resistivity	--		≥1014 Ω.cm
Chemical	Copper stability	168h at 158℃ 500mm/min.		Elongation≥100%
	Flammability	--		not flame retardant
Note: The test methods conform to UL224.
	Shrink ratio 3:1
Reference	As supplied(mm)	After recovered(mm)		Standard length
UPM S2VC	ID min.	ID max.	WT nom.	m/spool
1.5/0.5	1.5	0.5	0.5	200
3.0/1.0	3.0	1.0	0.7	200
4.5/1.5	4.5	1.5	0.7	100
6/2	6.0	2.0	0.8	100
9/3	9.0	3.0	1.0	50
12/4	12.0	4.0	1.1	50
15/5	15.0	5.0	1.2	50
18/6	18.0	6.0	1.3	50
24/8	24.0	8.0	1.5	25
30/10	30.0	10.0	1.7	25
39/13	39.0	13.0	1.9	25
50/16	50.0	16.0	2.5	25
60/20	60.0	20.0	2.6	25
70/23	70.0	23.0	2.6	25
80/26	80.0	26.0	2.8	25
90/30	90.0	30.0	2.8	25
100/33	100.0	33.0	3.0	25

ID=Internal Diameter		WT= wall thickness
Typical application
Ideal for electrical insulation,strain relief,wire bonding and light harness jacketing
Common applications include electronic systems of subway, aircraft, submarine
, control room facilities and sealed environment
Ordering
Standard color : Clear
