Grip & Non Skip X-Patten Textured Heat Shrink Tube Supplier's Choice

US$ 0.01 - 9.99 MOQ: 200 Meters

Key Specifications

Place of Origin:

Liaoning, China

Brand Name:

UPM

Model Number:

Union Polymer Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Liaoning, China

Brand Name UPM

Model Number S8

Type Other, No-slip

Material Composite Polymer

Application Low Voltage

Rated Voltage 1kV

Tensile Strength 10.4MPa

Specifications

Ideal for use as grips on tennis rackets, badminton rackets, fishing rods, baseball bats, billiard cue, hockey sticks ans so on

S8 Grip & Non Skid X-Patten Textured Heat Shrink Tube
Features
Flannel decorative surface		Operating temperature: -55~110 ℃
Excellent sweat absorption		Shrink temperature: min. 70 ℃
Economical and easy to install		Shrink Ratio:1.8:1
Well suited for the DIY market		Increases friction ans safety
Wide range of colors
Dimensions
Reference	As supplied(mm)	After recovered(mm)		Standard length
UPM S8	ID min.	ID max.	WT nom.	m
15	15.0	8.0	0.85	1
20	20.0	11.0	0.90	1
22	22.0	12.5	0.90	1
25	25.0	14.5	1.00	1
28	28.0	15.5	1.00	1
30	30.0	17.5	1.20	1
35	35.0	20.0	1.20	1
40	40.0	23.0	1.20	1
45	45.0	25.0	1.25	1
50	50.0	28.0	1.25	1
ID=Internal Diameter		WT=wall thickness

Technical Data
Property		Test method	Values
Physical	Tensile strength	ASTM D638	≥10.4 MPa
	Longitudinal shrinkage	ASTM D 2671	±5%
Electrical	Volume resistivity	ASTM D 2671	≥1014Ω.cm
	Dielectric strength	ASTM D2671	≥25 KV/mm

Typical application
Ideal for use as grips on tennis rackets, badminton rackets,fishing rods, baseball bats,
billiard cue, hockey sticks and so on.
Ordering
Standard color : Black,Red, Blue, Yellow, Green, other colors available on request
Standard packaging is 1.0m/pc, max. 1.5m/pc
Please specify specification, color, quantity when ordering
