Continuous Eps Pre-expander

Continuous Eps Pre-expander photo-1
Continuous Eps Pre-expander photo-2
Continuous Eps Pre-expander photo-3
Continuous Eps Pre-expander photo-4
Continuous Eps Pre-expander photo-5
Continuous Eps Pre-expander photo-6
US$ 5,000 - 7,800 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Foam Net
Place of Origin:
Zhejiang, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Product Type Foam Net
Place of Origin Zhejiang, China
Brand Name Milon
Model Number ML-900II
Voltage 380V/50HZ or customized
Power(W) 10kw
Dimension(L*W*H) 4700x2900x3200mm
Weight 3200KG
Certification CE
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

Continuous eps pre-expander



Product Description



---Product show---



1.Picture eps pre-expander

Continuous eps pre-expanderContinuous eps pre-expander

Continuous eps pre-expander

Continuous eps pre-expander



2.Technical data eps pre-expander

 ML-900IML-900Ⅱ
Expansion BarrelDiameterDN900DN900
Volume1.2m31.2m3
Usable Volume0.8m30.8m3
SteamEntryDN40DN40
Consumption200~250kg/h200~250kg/h
Pressure0.6~0.8MPa0.6~0.8MPa
Compressed AirEntryDN20DN20
Consumption0.5~0.8MPa0.5~0.8MPa
DrainageEntryDN20DN20
Throughput@15g/l150kg/h150kg/h
@20g/l200kg/h200kg/h
@25g/l250kg/h250kg/h
@30g/l310kg/h310kg/h
Material Conveying LineDN100DN100
Connected Load10kw10kw
Expanded densityFirst Expansion12~30g/l12~30g/l
Secondary Expansion7~12g/l7~12g/l
Overall Dimension(L*W*H)4700*2900*3200mm4700*2900*3200mm
Weight1600kg1600kg





3.Feature eps pre-expander

1.Inside and outside of barrel are both made of stainless steel, and the middle layer is heat preserving material, the production efficiency is 2~3 times higher than the average machine,it can reduce 25% energy consumption.



2.The baiting system includes first time baiting device and second time baiting device.



3.This machine can process secondary pre-expansion.



4.The expanded density range of foamed beads is 7~30 KG/M³,the density tolerance is minimal.



5.Steam pressure reducing valve is optional.



4.Application

Continuous eps pre-expander



5.Production flow of EPS machine

Continuous eps pre-expander





Packaging & Shipping



Company Information

 HANGZHOU MILON MACHINERY CO.,LTD was established by one professional team with more than 10 years experience on EPS machine and EPS assistant equipment. we have our own factories and partners to cooperate together. Our customers has been extended all over the world, the company is developing and growing up rapidly.



---Certificate---

Continuous eps pre-expander



---exhibition---

Continuous eps pre-expander



---Our major clients---

Continuous eps pre-expander

---EPS machine project in client factory---

Continuous eps pre-expanderContinuous eps pre-expander



---More for you choose---

Continuous eps pre-expanderContinuous eps pre-expander



Our Services



1. Value clients, guarantee equipment quality and answer clients’ questions anytime and anywhere.
2. Customizing machines according to clients' inquiry , such as different design, different brand parts, different colors, more function,etc.
3. Engineers go to clients' factory in time for installation , training and trial production .
4. 1 year free warranty, Lifetime technical service support, some spare parts will be send to our customer free of charge.



FAQ



Q1:what is warantty for EPS pre-expander machine?

1year waratty for free, lifetime service.



Q2: Do you have qaulity control?

Yes, we have QC team strictly inspect in the middle of production, 100% QC inspectbefore shipment.



Q3:What is advantage of your EPS machine?

Save steam, save electricity, high capacity, durable.



Q4: can you provide Vedio of machine working?

Yes, we are happy to provide vedio of EPS machine working if you need!
