22V DC Small Water Pump Motor Home

22V DC Small Water Pump Motor Home thumbnail-1
22V DC Small Water Pump Motor Home photo-1
Negotiable MOQ: 10000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
DONG HUI
Model Number:
RS-385PHV-12222R
Contact Supplier Request Quote Chat Now
Shenzhen Xin Dong Hui Motor Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shen zhen or Hong kong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name DONG HUI
Model Number RS-385PHV-12222R
Usage Fan, Home Appliance, Other, Fan, Home Appliance, Water Pump,Printer / Copy Machine/ ride-on car toys
Certification ROHS, Other, ROHS, ISO:9001:2000
Type Micro Motor
Torque 34mNm Stall torque
Construction Permanent Magnet
Commutation Brush
Speed(RPM) 4700rpm no load
Continuous Current(A) 0.05 A free-run
Voltage(V) 22
Efficiency IE 1

Specifications

DC Small Water Pump Motor in China
1. Ideal For Water Pump
2. 27.7*37.8mm Case
3. RoHS Compliant
4.4700rpm,0.05A free-run

Specifications

DC Small Water Pump Motor in China

1. Ideal For Water Pump

2. 27.7*37.8mm Case

3. REACH Compliant

4.4700rpm,0.05A free-run



22V DC Small Water Pump Motor in China( RS-385PHV-12222R )

DIMENSION DRAWING:



22V DC Small water pump motor home



1.MEASURING CONDITIONS
        1.1.Rated voltage:                     22   V DC
        1.2.Motor Position:                    To be measured with motor horizontally held.
        1.3.Environmental temperature:25±10°C.
        1.4.Environmental humidity:65%±20%RH.
2.ELECTRICAL CHARACTERISTICS(At initial stage after 30 seconds run-in):
        2.1.At No load
             2.1.1.Speed:                      4700 ±10% rpm
             2.1.2.Current:                    0.05   A(max  0.10 A)
        2.2.At Max Efficiency
             2.2.1.Torque:                     6.7mNm

             2.2.2.Speed:                      3778 ±10% rpm
             2.2.3.Current:                    0.21    A
        2.3.At Stall
             2.3.1.Torque:                     34mNm
             2.3.2.Current:                    0.84A



        2.4.Direction of Rotation:             CCW  (Counter-Clockwise when viewing from the output shaft end with positive voltage applied to positive terminal.



3.MECHANICAL CHARACTERISTICS

        3.1.Dimension drawing:               See<OUTLINE>.
        3.2.End Play:0.05~0.55mm                 MAX.
        3.3.Class H magnet wire.  Stainless steel shaft (304)
        3.4.Operating Temperature:                -10°C ~ +60°C.



PRODUCTION FLOW:
