1400 C Programmable lab used vacuum sintering furnace with silicon carbon heater
Application of vacuum sintering furnace
1.CVD experiment
2.Preparation of carbon nanotubes
3.Growth of graphene
4.Crystalline silicon substrate coating
5.Diffusion welding for metal materials
6.Heat treatment under the vacuum of atmosphere surroundings
Features of vacuum sintering furnace
1.Fast heating rate:20°c/min
2.Multi-function: CVD experiment, growth of graphene, crystalline silicon substrate coating and etc
3.LCD touch screen
4.50 steps programmable PID automatic control
5.Can connect with vacuum pump and atmosphere furnace.
6.Accept PC interface control
Technical parameters of vacuum sintering furnace
| Model | CY-T1400-60IT |
| Display | LCD touch screen |
| Chamber material | imported fiber |
| Heating element | SiC |
| Max.temperature | 1400℃ |
| Working temperature | ≤1350℃ |
| Heating rate | ≤20°c/min |
| Heating zone | single |
| Temperature zone length | 440mm |
| Thermostatic zone length | 200mm |
| Tube Material | high purity corundum |
| Tube Size | 50mm 60mm 80mm 100mm 1200mm |
| Tube length | 1200mm 1400mm |
| Flange connection | stainless steel flange |
| Control mode | PID automatic control via SCR power control |
| Temperature accuracy | ±1℃ |
| Working voltage | AC 220V 50-60Hz |
| Main power | 5kw |
| Packing | PLYwood box |
| Thermal couple | S type |
| Accessories | quartz tube 1pc, flange 1set, plug 4pcs,O-rings 8pcs, glove 1pair, alumina crucible 1set, furnace hook 1pc, manual book |
Picture of vacuum sintering furnace
Packaging of vacuum sintering furnace
PLY wood box as below picture, or as customer request.
Shipping and transportation
As customer request. Generally, Our mode of transport are as by sea, by air or rail transport
Payment
T/T, L/C, WEST UNION, PAYPAL, ESCROW AND ETC
Warranty
Main product is 15 month, except wearing parts.
Similar tube furnace
Factory show
Zhengzhou CY Scientific Instrument Co., Ltd is mainly engaged in the research and development, design, manufacturing and sales of equipment used in scientific researches. Independence and innovation is the company's tenet.
Processing room
Show room
Contact information
Skype ID: jennyhao8819
Whatsapp/wechat/viber:008615639272359
Tel:0086-0371-55199322
Fax:0086-0371-86036875
Website:
We are always at our service in 24 hours
Q 1.: Are you a trading company or a manufacturer?
A: We are the manufacturer, our factory is located in Zhengzhou city, Henan Provice, China. We welcome any of our potential customer and friends come to visit us.
We also have our own trade department to service our Foreign friends.
Q 2.: Can do customized?
A: Yes, we have own R&D department. Our engineer have worked in this field around ten years. We can design the equipment according the customer request.
Q 3.: What methods of the payment do you accept?
A: We accept: T/T, L/C, WEST UNION, PAYPAL, and Escrow
Q 4: How long will it take to get the delivery day?
A: It depends, general model, 1-5 sets, we can delivery within 10 days. Otherwise, we should check the details depend on the quantity and design.
Q 5: Do you have any overseas after-sales service office?
A: So far, we don't have overseas after sales service center. But, we promise all of our sincerley client that we will support the the after sale service for whole life of our equipment. Also, we will supply the accessories to our client by a value price. We also welcome the one whom want to be our after sale service supplier in their market, we can give them a trainning and accessories supplying.
Thank you for supporting our equipments and we welcome all of the people whom interested in our team come to visit us.
