Professional Manufacturer Auto Perfect Glue Binding Machine Glue Book Binding Machine

US$ 1 - 9,999 MOQ: 1 Piece

Key Specifications

Type:

Binding Machine

Computerized:

Yes

Place of Origin:

Zhejiang, China

Hangzhou Caide Office Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Type Binding Machine

Computerized Yes

Place of Origin Zhejiang, China

Brand Name WD

Model Number WD-986Z5

	Smart side-gluing application(Only BW-986V,BW-986Z5)	Advanced glue application system
	Smart Side-gluing application,no need any adjustment or setting ups.	Advanced glue application drum system gives the spine an even, uniform surface. (3 glue drums)

	Automatic creasing function	Digital controls spine glue length
	Automatic creasing function: The bond book directly goes to creasing station for creasing.	Digital controls spine glue length, no wasted books from excess glue build-up on the nipping station.

	Work table	Dust suction
	Folding work table easily holds paper,covers and books. It also speeds up the production.	Irritating fumes and waste particles are vented into and exhaust system, out of the building, or away from the work area.

	Open cover station	Smoke extrator
	Open cover station, easy for you to plance cover and take away finished book. Speeds up binding job.	Integrated fume extraction helps keep your work area comfortable and safe.

	Adjustable cover-clamping station	Digital speed adjustment
	Asjustable cover-clamping station meets demand of binding book with different kind of covers,as well as spine square adjustment	ording to opearator's skill.

Perfect Book glue binding machine / Glue Binder / Gluing machine

Main parameters:

Model	WD-950Z5	WD-970Z5	WD-986V	WD-986Z5
Max length	310mm	420mm(A3)	420mm(A3)	420mm(A3)
Max thickness	58mm	60mm	60mm	60mm
Binding speed	250-300 books/min	300-380 books/min	300-380 books/min	300-380 books/min
Warming Up	About 30 minutes		About 35 minutes
Milling system	Solar milling cutter+ small milling cutter
Clamping book	automatic
Clamping cover	automatic
Glue roller	single	3	3	3
Side Gluing	NO		YES
Milling foldpages	Three folding pages
Display	LCD
fine adjustment of clamp flat	YES
Open cover station	YES
worktable	YES
Digital control of spine gluing lenght	NO	NO	YES	YES
Smoke exhaust function	NO	NO	YES	YES
Speed adjustment	NO	NO	YES	YES
Auto-creaser	YES	YES	NO	YES
Power	AC220V(110V) 50Hz/60Hz 2300W	AC220V(110V) 50Hz/60Hz 2300W	AC220V(110V) 50Hz/60Hz 2800W	AC220V(110V) 50Hz/60Hz 2900W
Machine size	1740560970mm	2000650970mm	15206501030mm	20706501030mm
Net weight	170kg	190Kg	195Kg	225Kg
