CE certified PID control Laboratory 1700 degree Ceramic Sintering Electric Muffle Furnace
Technical parameters of electric muffle furnace
| Model | CY-M1200 | CY-M1400 | CY-M1700 |
| Chamber model | Side Door | ||
| Display | LED / LCD for optional | ||
| Limiting temperature | 1200℃ | 1400 ℃ | 1700 ℃ |
| Working temperature | ≤1150℃ | ≤1350℃ | ≤1650℃ |
| Heating rate | Suggestion 0~20℃/min | ||
| Temperature accuracy | ±1℃ | ||
|
Regular chamber size |
120*120*130(mm) | ||
| 150*150*150mm | |||
| 200*200*200mm | |||
| 200*200*300mm | |||
| 250*160*350mm | |||
| 250*250*300mm | |||
| 300*300*300mm | |||
| 300*300*400mm or as customized | |||
| Heating element | Aludirom | SiC | MoSi2 |
| Thermal couple | k Type | S Type | B Type |
| Temperature control | PID automatic control via SCR power control | ||
| Heating curves | 30 steps programmable(adjustable) | ||
| Chamber material | Alumina Fiber | ||
| Working voltage | AC 220V 50-60Hz, or as customized | ||
| Packing | PLY wood box | ||
| Accessories | Door stopper 1 pc, glove 1pair, crucible tongs 1pc, manual book | ||
Features of electric muffle furnace
1.Side door or slide door for optional, easy to operate
2.High quality alumina fiber, resistance high temperature
3.Intelligent control system, 30 steps or 50 steps programmable for optional
4.Metal key or touch panel operating interface for your option
5.Special heating element, no color green changing
6.Compact structure, low power, more energy saving.
7.Double cooling fan inside, even long time sintering, still can keep the chamber body cooling
Display of electric muffle furnace
Package of electric muffle furnace
Relative accessoreis
Zhengzhou CY Scientific Instrument Co.,Ltd is the real manufacturer whom is engaged in lab heat treatment equipment. Our main products include: tube furnace, muffle furnace, dental furnace, vacuum furnace, atmosphere furnace, mass flow controller and etc. We have separately R&D department, can do customized heat treatment equipment. Welcome you come to visit us.
Skype ID: jennyhao8819
Whatsapp/wechat/viber:008615639272359
Tel:0086-0371-55199322
Fax:0086-0371-86036875
Website:
We are always at your service within 24 hours
Q 1.: Are you a trading company or a manufacturer?
A: We are the manufacturer, our factory is located in Zhengzhou city, Henan Provice, China. We welcome any of our potential customer and friends come to visit us.
We also have our own trade department to service our Foreign friends.
Q 2.: Can do customized?
A: Yes, we have own R&D department. Our engineer have worked in this field around ten years. We can design the equipment according the customer request.
Q 3.: What methods of the payment do you accept?
A: We accept: T/T, L/C, WEST UNION, PAYPAL, and Escrow
Q 4: How long will it take to get the delivery day?
A: It depends, general model, 1-5 sets, we can delivery within 10 days. Otherwise, we should check the details depend on the quantity and design.
Q 5: Do you have any overseas after-sales service office?
A: So far, we don't have overseas after sales service center. But, we promise all of our sincerley client that we will support the the after sale service for whole life of our equipment. Also, we will supply the accessories to our client by a value price. We also welcome the one whom want to be our after sale service supplier in their market, we can give them a trainning and accessories supplying.
Thank you for supporting our equipments and we welcome all of the people whom interested in our team come to visit us.
Consulting hotline: 0086-0371-55199322 (86)15639272359
