U shape Molybdenum Disilicide heating element / MoSi2 heating elements / MoSi2 heater
The General Descrioition Of high temperature MoSi2 heater
1. U shape mosi2 heaters is a kind of resistance heating element basically made of high pure Molybdenum Disilicide.
2. In oxidizing atmosphere, its Max temperature can reach 1800 deg.C, and its applicable temperature is 500~1700 deg.C.
3. It can be widely used in such applications as sintering and heating treating of ceramic, magnet ,glass, metallurgy ,refractory, ect.
4.physical property of the MoSi2 heater
| volume density | 5.5~5.6g/cm³ | bend strength | 5.5~25kg/cm² |
| vickers-hardness | (hv)570kg/mm² | porosity rate | 7.4% |
| water absortion | 1.2% | hot extensiblity | 4% |
5.Recommend surface load:
| Furnace Temp(°c) | 1400 | 1500 | 1600 | 1650 | 1700 |
| Surface looad of hot zone(W/cm²) | <18 | <15 | <12 | <10 | <8 |
When you enquiry, please tell us the following data:
(1) Diameter: D1/D2, mm/mm
(2) Hot zone length: Le, mm
(3)Code Zone length: Lu, mm
(4) Shank Spacing: A, mm
display of the MoSi2 heater
