Commercial and Industrial Bus&truck Spray Booth, Special Paint Oven
US$ 20,000 - 35,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Power:
57KW
External Size:
15000x5000x5000mm
Internal Size:
15150x6750x5600mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Paint Mixing Room, Paint RoomUS$ 1,500 - 2,500MOQ: 1 Set -
Paint Prep Station, Prep Station Spray Booth, Preparation ZoneUS$ 3,000 - 7,500MOQ: 1 Set
-
Car Painting Booth, Car Painting Booth PriceUS$ 6,000 - 9,000MOQ: 1 Set
-
Quick Curing System Water Curtain Spray BoothNegotiableMOQ: 1 Set
-
Used Spray Booth for Sale, CE Certification Car Paint Spray BoothUS$ 5,000 - 11,000MOQ: 1 Set
Power
57KW
External Size
15000x5000x5000mm
Internal Size
15150x6750x5600mm
Certification
CE
Place of Origin
Jiangsu, China
Brand Name
Youda
Truck spray booth
Commercial and industrial bus&truck spray booth, special paint oven
Provide spraying, accelerated drying or baking in one clean, fast operation. Operators may herefore work with complete comfort and confidence, using virtually any type of today’s paint materials.
16M spray booth specification recommend
| Inside Dimensions: | 16000(L)X5000(W)X5000(H) mm | |
| Outside Dimensions: | 16150(L)X6750(W)X5600(H) mm | |
| Booth | Without basement, pit type, 2 rows of grating; With 2 lifts inside of booth |
|
| Wall Panels: | Thickness: 75mm, double skined with polystyrene insulation(EPS) inside, tongue and groove interlock construction | |
| Roof Panels: | 50mm EPS ceiling panel; C-shape ceiling filter holders, powder coated. | |
| Doors: | Drive Through of auto Main door, 4000(W)x4500(H) mm. 2 sets of personnel doors, 800(W)x2000(H) mm,with Tempered glass observation window; 1 set of middle auto door; |
|
| Generator Setting | Aluminum ally frame | |
| Intake: | 2 sets intake system, each set with 2x7.5KW centrifugal fan. Capacity:80000cmh | |
| Extract: | 2 sets extract system, each set with 1x11KW siemens motor; centrifugal fan, capacity:60000cmh With manual value to adjust the pressure of inside booth |
|
| By-Pass: | Pneumatic damper from spraying to baking cycle | |
| Heating System: | 2 sets of heating system, each set with Italy Riello 1xRG5S oil burner, total 520000Kcal/h heating capacity Stainless heating exchanger, heat exchange efficiency ≥85% |
|
Special designs are available on request.
