CE Certification and Spray Booths Type Auto Spray Booth
US$ 6,000 - 9,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Power:
13KW
External Size:
7000x5400x3400
Internal Size:
6900x3900x2650
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Painting Cabin, Car Paint Cabin Price, Cabins Are for Painting CarsUS$ 5,000 - 12,000MOQ: 1 Set -
Preparation Station Spray Booth, CE Approved Spray Booth for SaleUS$ 6,000 - 13,000MOQ: 1 Set
-
Side Down Draft Spray Booth, Semi Down Draft Spray BoothUS$ 6,000 - 9,000MOQ: 1 Set
-
Non-standard Industrial Spraybooth, Non Standard Size BoothsUS$ 15,000 - 35,000MOQ: 1 Set
-
Downdraft Spray Booth, Automotive Paint Spray Booth, Spray Booths to Body Shops,US$ 7,000 - 9,000MOQ: 1 Set
Power
13KW
External Size
7000x5400x3400
Internal Size
6900x3900x2650
Voltage
380V
Certification
CE
Place of Origin
Jiangsu, China
Brand Name
Youda
Model Number
DA800
Auto spray booth
Features:
| Model: | DA- 800 IIA | DA- 800 IA |
| Inside Dimensions: | 6900(L)X3900(W)X2650(H) mm | |
| Outside Dimensions: | 7000(L)X5400(W)X3400(H) mm | |
| Wall Panels: | Thickness: 50mm, double skined with polystyrene insulation(EPS) inside, tongue and groove interlock construction | |
| Roof Panels: | Galvanized steel sheet; C-shape ceiling filter holders, powder coated. | |
| Doors: | 3-fold main doors, 3000(W)x2600(H) mm. One personnel door, 800(W)x2000(H) mm | |
| Basement and Floor: | 300mm high raised metal- base with 2 pcs ramps outside, 2 rows of gratings and 3 rows of indented plates. | |
| Generator Setting | Aluminum ally frame | |
| Intake: | One backward inclined turbo fan, capacity:15000cmh,motor:5.5kW, direct drive | Two double-intake centrifugal fans, capacity:20000cmh, motor: 2x3kW, belt drive |
| Extract: | One backward inclined turbo fan, capacity:15000cmh,motor:5.5kW, direct drive | One double-intake centrifugal fan, capacity:15000cmh, motor:5.5kW, belt drive |
| By-Pass: | Pneumatic damper from spraying to baking cycle | Pneumatic damper from spraying to baking cycle |
| Heating System: | Stainless heating exchanger, 60°C - 80°C working temperature. Italy Riello RG20 oil burner, capacity 180000Kcal/h | |
| Filter System: | 4 sorts of filters: prefilter, ceiling filter, floor paint-stop filter, activated carbon filter. | |
| Lighting: | 8 units 4×36W inclined ceiling lights, 8 units 2×18W horizontal side lights. Philips tubes, Illumination≥1000Lux. | |
| Control System: | Reliable components, digital temperature readout, spray and bake temperature settings, bake timer,spray and bake switch, pressure gauge, emergency stop. | |
| Total Power: | 12.5KW | 13KW |
All components are recognized, listed or certified by CCC,UL,ETL, CAS or CE.
Parts of spray Booth
Facility
Packing
