1200C laboratory crucible muffle furnace / crucible heat treatment furnace
Brief introduction of the crucible furnace:
CY-CF1200 series crucible Furnace are the most effective high temperature furnace, Furnaces are made with high quality alumina fiber brick. They are designed with double shell with fan cooling which can make temperature raising quickly but keep outside similar as door temperature. Furnace temperature is controlled by high precision SCR digital controller with accuracy ±1'C an 30 sements programmable.
Specification of the high temperature crucible furnace :
| Item | CY-CF1200 high te crucible furnace |
| Power | electric |
| chamber size |
240x220mm (Dia*height) also can be designed as your requirement |
| chamber material | quartz, or alumina chamber |
| furnace structure | double shell with fan cooling, side open |
| max.temperature | 1200'C |
| working temperature | 1100'C |
| temperature accuracy | ±1'C |
| heating element | high quality resistance wire |
| thermocouple | K type |
| working voltage | 220V,single phase, 50/60HZ |
| temperature control | 30segments programmable and PID auto control |
| heating rate | suggest 0-20'C/minute |
| warranty | one year warranty period, not including consumable components such as heating element |
Display of the high temperature crucible furnace:
Zhengzhou CY Scientific Instrument Co., Ltd.- is a high and new technology enterprise registered in Zhengzhou,Henan province. Zhengzhou CY Scientific Instrument Co., Ltd is mainly engaged in researching and developing, designing and manufacturing of equipment used in scientific researches.
Our mainly products include high temperature furnace and heating element, like lab muffle furnace, tube furnace, dental furnace, vacuum furnace,gold melting furnace, SiC heating element, MoSi2 heating element, alumina tubes and crucibles, and etc.
