Best Price for Small Permanent Magnet Vibrating Table

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port shanghai/ningbo
Payment TermsMoney Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	TENLEE
Model Number	VT	Power	Electronic
Usage	Vibration Testing Machine

Product Description

Specifications

1.high energy,cost efficient
2.vibration test applications
3.educational,research,lab
4.wide frequency,reasonable structure

1.Introduction

VT series Permanent Magnetic Vibration Exciters are the high-quality, compact machine with a permanent magnetic field. It is designed for long, trouble-free operation, and has a force rating from 10N to 1000N enabling relatively heavy loads to be excited to high g levels. The moving element is supported by a robust rectilinear guidance system consisting of grouped radial and transverse flexures in a unique construction. The flexures are made from a bonded sandwich of spring steel and a damping elastomer, providing a clean acceleration waveform with low cross motion and low distortion characteristics.

2.Applications

These electrodynamic vibration exciters are typically part of the vibration test equipment used in educational, research and laboratory environments.

Vibration testing
Mechanical impedance measurements
Educational demonstrations
Structural response testing
Modal analysis
separation and compacting of powders
small component vibration screening
Vibration transducer calibration

3.Specifications

Model	VT-20	VT-50	VT-150	VT-300	VT-500	VT-1000
Rated Force	≥20 N	≥50 N	≥150 N	≥300 N	≥500 N	≥1000 N
Max. Displacement	± 4 mm	± 5 mm	± 7.5 mm	± 7.5 mm	± 12.5 mm	± 12.5 mm
Max. Acceleration	20 g	20 g	40 g	45 g	45 g	45 g
Max. Velocity	1.4m/s	1.4m/s	1.4m/s	1.4m/s	1.4m/s	1.4m/s
Maximum Input Current	≤2.5 Arms	≤6 Arms	≤12 Arms	≤12 Arms	≤25 Arms	≤30 Arms
Frequency Range	20 to10kHz	10 to 9kHz	10 to 5k Hz	10 to 5k Hz	5 to 2k Hz	5 to 2k Hz
Coil DC Impedance:	2Ω	0.9Ω	0.8Ω	0.7Ω	0.7Ω	0.7Ω
Moving Element	0.1 Kg	0.25 Kg	0.45 Kg	0.54 Kg	1.1 Kg	2.2 Kg
Size(mm)	Φ96×132H	Φ138×165H	Φ180×175H	Φ180×200H	Φ220×260H	Φ240×350H
Mounting Size(mm)	105×80 /4-Φ9	150×120 /4-Φ10	200×160 /4-Φ10	200×160 /4-Φ10	240×190 /4-Φ11	240×200 /4-Φ10
Weight	3.3 Kg	8.5 Kg	13.5 Kg	18.5 Kg	29 Kg	42 Kg
Output Type	TableΦ26/ M5	TableΦ30/ M5	TableΦ40/ M5	TableΦ50/ M5	TableΦ70/ M5	TableΦ80/ M5
Associated Amplifier	100W	100W/200W	200W/500W	500W/500W	800W	1500W

4. Packaging

5. Our products:

Vibration Accelerometers

Vibration Velocity Sensors;

Vibration Displacement(Eddy) Sensors

Quartz Force IEPE Sensors

Quartz Pressure IEPE Sensors

Signal Conditioners

Data Acquisition Systems

Power Amplifiers

Modal Shakers

Small Vibrators

Vibration Calibrators
