12volt 30a Auto Relay

Name: 12volt 30a Auto Relay
Brand: LANGQI
SKU: 112033503

US$ 0.46 - 1 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

LANGQI

Model Number:

LQ680

Yueqing Tenlee Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name LANGQI

Model Number LQ680

Theory Other

Usage Auto

Size Miniature

Protect Feature Sealed

Contact Load Other

12v Automotive Relay

External Dimension & Wiring Diagram

30A switching current

Integrated components (e.g. resistor, diode)

Customized marking/color

Suitable for control kinds of automobile circuits

Excellent shake resistance performance

Outlet terminal of swift connection type

Sealed enclosure waterproof

With couple socket

Outline size (mm): 28 X 28 X 25(+16)

Auto Relay Contact Data
Contact Form	1A SPST(NO); 1B SPST(NC); 1C SPDT(B-M); 1U SPST(NODM)
Contact Material	Silver Alloy
Contact Resistance	50mΩ (1A 6VDC)
Contact Rating	1A	1B	1C	1U
	40A/14VDC	30A/14VDC	NO:40A/14VDC; NC:30A/14VDC	2 X20A/14VDC
Max. Operating Voltage	250VAC/30VDC
Max. Operating Power	7500VA/900W
Electrical Endurance	10^5 times
Mechanical Endurance	10^7 times

Auto Relay Coil Rating
Nominal Coil Power	1.8W

Auto Relay Operation Specification
Insulation Resistance	100mΩ 500VDC
Dielectric Strength	BCC 50Hz 500V
Dielectric Strength	BOC 50Hz 500V
Operate/Release Time	10ms/5ms
Terminal Type	Outlet terminal
Ambient temperature	-40~85°C
Weight	31g, 35g(with iron bracket)
