Home > Instruments & Meters > Analysis Instrument > Other Analysis Instruments > Usb Interface 4,8,16,32 Channel Dynamic Data Acquisition and Analysis Unit

Usb Interface 4,8,16,32 Channel Dynamic Data Acquisition and Analysis Unit

Name: Usb Interface 4,8,16,32 Channel Dynamic Data Acquisition and Analysis Unit
Brand: TENLEE
SKU: 112032841
Availability: InStock

Usb Interface 4,8,16,32 Channel Dynamic Data Acquisition and Analysis Unit thumbnail-1

Usb Interface 4,8,16,32 Channel Dynamic Data Acquisition and Analysis Unit photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

TENLEE

Model Number:

TL 9000 series

Contact Supplier Request Quote Chat Now

Yueqing Tenlee Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai/ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name TENLEE

Model Number TL 9000 series

Specifications

1.applications in dynamic signal analysis
2.4,8,16,32 analog input channels
3.IEPE sensor conditioning,USB 2.0 host interface

1.Introduction

dynamic data collector, it is a kind of multichannel parallel data acquisition system based on USB2.0 interface;

With voltage/IEPE two input mode; Multi-channel arbitrary combination, support for multiple devices cascade, built-in programmable gain amplifier and real-time digital filtering; Supporting function rich in universal test and analysis

software; Provide the LabView and MATLAB data interface, convenient and subsequent data processing; Particularly a

pplicable to the company production of force and acceleration sensor matching vibration measurement data

acquisition/analysis system, the modal test system, etc.

2.Features

Our systems support the widest range of applications in dynamic signal analysis:

4,8,16,32 analog input channels

100 kHz simultaneous sampling

IEPE sensor conditioning

TEDS support

USB 2.0 host interface

3.Specifications

Model		9004	9004H	9204H	9208	9216	9232
Channels	Input(AD)	4	4	4	8	16	32
	Output(DA)	0	0	2	2	2	2
Input Signal Range	Voltage	±10VPEAK	±8.8VPEAK	±10VPEAK	±10VPEAK	±10VPEAK	±10VPEAK
	IEPE	±10VPEAK	±8.8VPEAK	±10VPEAK	±10VPEAK	±10VPEAK	±10VPEAK
Input Signal Frequency Range	Voltage	DC to 50kHz	DC to 200kHz	DC to 100kHz	DC to 50kHz	DC to 50kHz	DC to 50kHz
	IEPE	0.3Hz to 50kHz	0.3Hz to 200kHz	0.3Hz to 1 00kHz	0.3Hz to 50kHz	0.3Hz to 50kHz	0.3Hz to 50kHz
Signal Input(AD)	Signal Channel Sampling Rate	100kHz	3MHz	1MHz	100kHz	100kHz	100kHz
	Simultaneous Sampling Rate	100kHz	750kHz	1MHz	100kHz	100kHz	50kHz
	AD bits	24	16	16	24	24	24
	Bulit-in Gain	×1 ,×10 , ×100	×1 ,×10	×0.1 , ×1, ×10 ,×100	×1 ,×10,×100	×1 ,×10,×100	×1 ,×10,×100
	Accuracy	≤±0.5%	≤±0.5%	≤±0.5%	≤±0.5%	≤±0.5%	≤±0.5%
Signal Output( DA)	Conversion Rate	-	-	500kHz	500kH	500kHz	500kHz
	Analog Output Range	-	-	±10VPEAK	±10VPEAK	±10VPEAK	±10VPEAK
	Accuracy	-	-	≤±1%	≤±1%	≤±1%	≤±1%
Size(mm)WHD		100×122×45	196×122×45	240 ×69×277	240 ×69×277	240 ×69×277	340 ×132×277
Weight		460g	750g	3.5kg	3.5kg	4.0kg	6.5kg
Power Supply		USB Self –powering	7.5VDC	220V50Hz	220V50Hz	220V50Hz	220V50Hz
